ABB palletizing robot palletizing manipulator

Product features: The most advanced 4-axis design is adopted. It is a high-speed robot with 3.15m arrival distance and 250kg payload, which is very suitable for stacking materials in the form of bags, boxes, Flat noodles, bottles and other packaging forms.
Strong reliability - long normal operation time
The IRB 660 robot has significantly improved motion speed compared to its predecessor, and its optimized motor power and motion performance make it have a shorter cycle time compared to similar products.
Fast speed - short operation cycle time
Using standard packaging software.
High precision - stable production quality of parts
It has extremely high repeatability accuracy (± 0.03mm) and trajectory accuracy.
High power - wide range of applications
The high-speed version of the IRB 660 robot can reach a payload of 180kg at full speed, while the high-yield 250kg version of the robot can reach a maximum distance of 3.15m.
Durable and sturdy - suitable for harsh production environments
The robot is sturdy and durable, with an IP67 protection level, and maintains stable performance even in the harshest production environments.
Universality - Flexible Integration and Production
The robot has a very large reach distance and can simultaneously handle 4 feeding conveyor belts, 2 pallet stacks, 1 sliding pallet stack, and 4 stacking and discharging lines. The versatility, reach distance, and load-bearing capacity of the IRB 660 robot can almost meet the requirements of any stacking application.
Main applications: palletizing, unstacking, material handling
Specifications:
1. Load capacity: 250KG
2. Arrival distance: 3.15M
3. Number of axes: 4
4. Protection level: IP67
5. Installation: Landing
6. Robot base size: 1136 * 850MM
7. Robot weight: 1650KG
8. Repetitive positioning accuracy (RP): 0.10mm
9. Repetitive cycle accuracy (RT): 0.30MM
