American UL certification RHH low smoke halogen-free UL44 standard energy storage cable

NegotiableUpdate on 01/15

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

Mainly wired through gullies, pipelines, etc., it is usually used for power distribution, service, feeder, and branch circuit wiring in residential, industrial, and commercial buildings. $r $n $r $n has good heat resistance, compression resistance, and environmental cracking resistance. At the same time, such products also have good moisture resistance, UV resistance, low toxicity, and low smoke and halogen-free properties. $r $n $r $n can be used for up to 90& #176; In a dry environment, the rated voltage is divided into two types: 600V or 2000V.

Product Details

cable structure

The conductor is annealed copper soft conductor,comply withASTM B3orNMX-J-036-ANCE

Insulation material is a thermosetting cross-linked polyethylene with low toxicity, moisture resistance, UV resistance, low smoke and halogen-free properties, and flame retardancy（XLPE）

Colors available for selection

Product Features

The ambient temperature during laying shall not be lower than-At 5 ℃, the bending radius of the cable shall not be less than 10 times the outer diameter of the cabletimes

During a short circuit (maximum duration not exceeding)5s）The maximum temperature of the cable conductor shall not exceed250℃

Has excellent electrical performance and high breakdown electric field strength

Tangent value of dielectric loss angleSmall tan δ, high insulation resistance, excellent insulation performance

Has high heat resistance and aging resistance, allowing for high operating temperatures and large current carrying capacity

The cable can withstand significant mechanical external forces and tensile strength, and is easy to lay and maintain

standard

UL44
