Bag style chili sauce filling machine

Bag style chili sauce filling machine

Product Overview:
The bag type chili sauce filling unit consists of bag type packaging equipment and liquid (food) packaging equipment, equipped with a liquid stirring device to prevent the precipitation of micro particle materials, and a liquid level control device.
Packaging samples:

Scope of use:
Suitable for packaging liquid and paste materials, such as detergents, soy sauce, fruit juice, tomato sauce, chili sauce, Douban sauce and other materials in bags.
Schematic diagram of the eight station operation of the bagged chili sauce filling machine:

Main reference parameters:

model	XH-6/8-200Y
Equipment Composition	Bag packaging equipment, liquid (food) measuring instruments
Bag making type	Self standing bags (with and without zippers), flat bags (three sided sealed, four sided sealed, tote bags, zipper bags), paper bags and other composite bags
Scope of Application	Detergent, yellow wine, soy sauce, fruit juice, tomato sauce, jam, chili sauce, Douban sauce, etc
packaging precision	≤±1%
packaging speed	≤ 35 packs/minute (the speed is determined by the material itself and the weight of the filling)
Bag size (mm)	Bag width: 100-200mm Bag length: 100-300mm
power supply voltage	Three phase 380V 50HZ/60HZ
Power consumption (kW)	5KW
Compressed air consumption	0.6m3/min (provided by the user)
packaging form	heat sealing

Show the bag style chili sauce filling machine:
