DJI FC100 drone - provided for emergency/industrial/agricultural transportation. DJI FC100 is the flagship civilian transport drone of DJI, with "80kg heavy load+9-minute fast charging+omnidirectional safety protection" as the core, suitable for multiple scenarios such as emergency, power, engineering, logistics, etc., breaking through complex terrain transportation and redefining low altitude professional transport standards.
DJI FC100 drone - providing emergency/industrial/agricultural transportation
Heavy duty dual-mode adaptationThe maximum load capacity of single electric mode is 80kg, covering point-to-point transportation of heavy materials (power insulators, engineering equipment); The dual electric mode has a load capacity of 65kg and a range of 12km, which meets the requirements for medium to long distance operations. The maximum range without load is 26km. Equipped with 62 inch carbon fiber blades and upgraded motors, the maximum single axis tension is 82kg, and the power redundancy exceeds 100%.
Fast energy replenishment and endurance guaranteeThe 41Ah large capacity battery supports 1500 warranty cycles and is equipped with a dedicated charger for 9-minute fast charging. Low temperature environment can automatically heat up, supporting dual battery hot replacement and redundant design, achieving 24-hour uninterrupted operation.
Triple Perception Security SystemLidar (300000 point/second point cloud data)+millimeter wave radar+five eye fisheye vision, omnidirectional detection of small obstacles. Innovative obstacle avoidance algorithms can protect both the aircraft and cargo simultaneously, coupled with upgraded parachutes (deployed above 100 meters, ground contact speed ≤ 6m/s), to build a strong safety defense line.
Intelligent aerial suspension systemThe flagship version supports automatic retraction of a 30 meter rope (with a heavy load retraction speed of 1.2 meters/second), electric opening and closing hooks, automatic anti swing, real-time weighing, automatic deceleration of goods near the ground, and remote control of hooks or one click release of ropes to escape. The dual electric version comes standard with a fixed rope length of 10 meters, suitable for simple scene requirements.
Full scene environment adaptationIP55 protection can cope with rain, snow, sand and dust weather. It is suitable for high-altitude operations at an altitude of 6000 meters and has a wind resistance of 12m/s. It can easily handle complex airflow and overcome terrain and climate limitations.
Efficient and intelligent homeworkDJI's Yunyun platform supports one click route planning, AR guidance at loading and unloading points, and multi perspective assisted flight. In the event of a disconnection, pre-set waypoint actions can automatically complete transportation. The all-new DJI Delivery App displays real-time flight status and cargo information, significantly reducing operational barriers.
Flexible expansion and collaborationOpen PSDK interface and 3000 watt high-power interface, supporting external third-party loads (thermal imaging, detection equipment). Yunyun Docking 2.0 can connect to third-party platforms to meet industry customization needs.
Stable signal transmissionThe 20km O4 image transmission signal is stable and can automatically switch to 4G enhancement modules or relay through D-RTK3 base stations to solve signal interference problems such as mountain obstruction.
emergency rescueWhen the road is interrupted, drugs, food, and equipment can be quickly delivered. The 30 meter rope is suitable for precise unloading in complex terrain, and contactless delivery reduces cross risk and shortens emergency response time by 50%.
power transmissionWith a load capacity of 80kg, it can lift large objects such as lightning rods and insulators, and complete the manual 6-hour climbing of mountain line materials transportation in 15 minutes, greatly reducing operation and maintenance costs.
construction projectTransporting cement, sand and gravel, as well as small and medium-sized construction machinery, can complete more than ten kilometers of mountain and forest transportation tasks in a single operation, replacing manual handling and improving operational efficiency by 20 times.
mountain logisticsSuitable for remote rural areas, islands and other areas with inconvenient transportation, postal and agricultural supplies can be transported directly by air, compressing the two-hour postal route to just over ten minutes and reducing the transportation cost to as low as 1.4 yuan per ton per kilometer.
Load operationThe flagship version of the aerial crane requires pre calibration of the weighing sensor, and a safety margin should be reserved for the rope length setting; The fixation of goods requires balancing the center of gravity to avoid deviation during heavy load flight.
Charging ManagementSupports three energy replenishment methods: C12000 intelligent charger (three-phase power), CC15000 car charger, and D14000iE field charging station. After charging, the battery temperature and power level need to be checked.
Environmental adaptationBefore flying in high-altitude/low-temperature environments, the battery heating function should be turned on to reduce the load capacity and ensure endurance; Avoid low altitude flight in strong wind weather and activate roll free flight mode to improve stability.
routine maintenanceRegularly clean the radar and visual sensor lenses, and check the wear of the blade locking buckle and rope; Perform a comprehensive inspection of the motor and brake every 50 hours of flight.
