AUTOID Pad Air - (Win) Industrial Tablet Industrial Tablet Features:
Lightweight design, easy to handle mobile tasks:
10.1-inch lightweight industrial grade tablet computer;
Lightweight to use, not noticeable in the hands, rejecting homework fatigue and hand soreness;
Built in scanning head design, bidding farewell to the protrusion caused by the scanning head on the body.
Surge performance, instantaneous response processing requirements:
Intel dual core processor, optional 8100Y high-performance processor, paired with higher running memory and solid-state drive;
Strong performance, balanced power consumption, always on standby, meeting performance requirements in various scenarios.
Professional scanning module, smooth scanning experience:
Paired with scanning tools on the Windows platform to meet customers' daily scanning needs.
Data transmission, suitable for various scenarios:
Supports WiFi 6 and 2 × 2 MIMO high-speed wireless networks for faster and more stable data transmission;
Support 4G carrier aggregation technology, allowing for faster speeds and excellent network performance both indoors and outdoors;
Bluetooth 5.0 makes it easy to connect Bluetooth peripherals such as scanners, headphones, printers, etc.
Long lasting battery life, continuous operation for a whole day:
4920mAh large capacity battery, AI intelligent power-saving technology, Type-C 300000 fast charging technology, continuous use for 8 hours.
Lightweight yet still sturdy:
IP65 waterproof rating, 1.2m drop, has undergone over 60 reliability tests, and is suitable for various harsh environments.
AUTOID Pad Air - (Win) industrial grade tablet/industrial tablet computer parameters:
1 AUTOID ® Pad Air - (Win) series tablet performance, physical and usage environment parameters
CPU/graphics card
Intel Celeron 3965Y， 2 cores and 2 threads, 1.5Ghz/Intel HD 615, basic frequency 300MHz, maximum dynamic frequency 850MHz
Intel Core M3-8100Y， 2 cores and 4 threads, 1.1GHz, maximum turbo frequency of 3.4GHz/Intel UHD 615, basic frequency of 300MHz, maximum dynamic frequency of 900MHz
Operating System Windows 10 Enterprise 64 bit
Memory/Hard Disk
4GB (Samsung LPDDR3 1867MHz) 64GB (SanDisk)
8GB (Samsung LPDDR3 1867MHz) 128GB (Kingston/Solid State Drive customizable 256GB)
User storage expansion
Interface/Communication
Micro SD Card， Support for SDCC
TYPE-C interface, supports host charging, supports USB 3.0 (backward compatible with USB 2.0), supports
DisplayPort， Support headphones, etc
The SIM card slot supports Nano SIM cards
Three buttons (power, volume+, -)
display screen
10.1-inch full view LCD display, capacitive 10 point touch, supports glove wearing/water touch
Resolution 1920 × 1200, normal brightness (customizable high brightness 800nit)
power supply
Bottom contact interface DC IN: maximum input power 27W
Non removable 7.7V lithium-ion rechargeable battery
Typical value 5070mAh
Rated value 4920mAh
USB TYPE-C interface, supporting PD fast charging
Bottom contact expansion interface USB 2.0, 5V output, DC input IO
indicator light
A red green dual color: red charging indicator and green working status indicator.
A red blue dual color light: blue (reserved), red scanning indicator light.
Audio with built-in stereo speakers, 4 Ω 2W * 2. Built in dual microphones. Supports TypeC digital earphones.
Sensor, accelerometer, ambient light sensor
Hand strap standard
Size 258 * 173 * 10.8 (12) mm
Weight (including standard battery) 690g (weight may vary depending on configuration)
Working temperature -10 ℃ to+50 ℃
Storage temperature -20 ℃ to+60 ℃
Humidity 5% to 95% RH without condensation state
Waterproof and dustproof industrial grade IP65
Drop grade 1.2 meters smooth marble
Electrostatic discharge (ESD) ± 15kV air discharge, ± 8kV direct discharge
2、 AUTOID Pad Air - (Win) tablet data acquisition function parameters
Function 1: Advanced 2D Image Scanning Engine (optional)
Image resolution 1280 * 800
Field of view angle horizontal 57.6 °, vertical 44.4 °, resolution 5 mil
LED supplementary light source color temperature: 2700K; service life: in accordance with IESNA LM-80 standard
AIMER graphic: Cross laser graphic
Laser safety level Class II
Supporting symbols
1D: UPC/EAN, Code128, GS1-128, Code 39, Code 93, Interleaved 2 of
5. Codabar et al. 2D: PDF417, MicroPDF417, Data Matrix, QR Code, MicroQR, etc. (varies depending on different software versions)
Working temperature: 0 ℃ to 50 ℃
Optional white standard light source for illumination
Frame rate 60fps
recognition accuracy
One dimensional code: 3mil
QR code: 4mil
Function 2 Geographic location information collection
Positioning GPS+GLONASS+BeiDou+Galileo, QZSS, supports AGPS
Working mode GPS main positioning, Beidou, GLONASS, Galilieo auxiliary positioning
Frequency GPS: L1 (1.575GHz); Beidou: B1 (1.561GHz); GLONASS:L1(1.602GHZ）
Accuracy 5-10 meters
Function 3: Front camera image acquisition
2 million pixels
Camera function fixed focus
Function 4: Rear camera image acquisition
8 million pixels
Automatic autofocus function for photography
Flash supports photo mode flash
Function 5 RFID (HF)
Readable label
Supports ISO15693, ISO14443A/B (without encryption protocol), ISO14443A tags with encryption protocol (Mifare one S50, S70 and compatible cards);
Working frequency HF band 13.56MHz
Reading distance: 0~6cm (ISO15693), 0~4cm (ISO14443A/B (depending on the label)
Function 6: Fingerprint Collection (Customizable)
Fingerprint collection 508DPI, 256 * 360pix, supports fingerprint collection, second-generation certificate fingerprint module
3、 AUTOID Pad Air - (Win) Tablet Wireless Data Communication Function Parameters
Function 1 Wireless LAN WIFI
Protocol WIFI 6, IEEE 802.11a/b/g/n/ac/ax (2.4G/5G dual band WIFI) 2X2 MIMO
frequency range
Depending on the country (region), 2.4GHz is typically between 2.412GHz-2.472 GHz; 5GHz is between 5.170GHz-5.835GHz
Working channels CH1~CH13, CH34-CH64, CH100~144, CH149~CH165
safety
OPEN、WEP、WPA2-PSK（TKIP+AES）、EAP-TLS、EAP-TTLS/ MS-CHAPv2、PEAPv0-MSCHAPv2、AES 等。 Intel vPro Technology、Intel Active Management Technology
Transmission distance 2.4G greater than 250 meters, 5G greater than 200 meters (industrial grade AP, open area)
Data rate
802.11a: 6,9,12,18,24,36,48,54Mbps
802.11b: 1, 2,5.5,11Mbps
802.11g: 6,9,12,18,24,36,48,54Mbps
802.11n: 6.5,13,19.5,26,39,52,58.5,65Mbps（20MHz,Long GI,800ns)
802.11n: 7.2,14.4,21.7,28.9,43.3,57.8,65,72.2Mbps（20MHz,short
GI,400ns)802.11ac：20MHz/40MHz/80MHz/160MHz MCS0~MCS9802.11ax：20MHz/40MHz/80MHz/160MHz MCS0~MCS11
Function 2 Wireless Wide Area Network
frequency band
WCDMA：B1/B8
CDMA：BC0
TDD-LTE：B38/B39/B40/B41
FDD-LTE：B1/B3/B5/B8
通信速率
LTE-FDD maximum downlink 150M, uplink 50M
LTE-TDD downlink 130M, uplink 35M
Function 3: Wireless Personal Area Network Bluetooth
Standard Bluetooth 5.0 (dual-mode, supporting BLE)
Distance greater than 20 meters (industrial grade Bluetooth adapter)
4 AUTOID ® Pad Air - (Win) third-party application development support
System software Windows 10
System programming environment Visual Studio
5 AUTOID ® Pad Air - (Win) Accessories
Standard accessories: PD fast charging adapter x 1, dual TYPEC data cable x 1, hand strap x 1
Optional accessories include a single multi-functional seat charger, silicone protective cover, tempered film, and shoulder strap for the entire machine
