French Euro Shen Level III Power Surge Protector [Beam Lightning Protection]

NegotiableUpdate on 04/06

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

French Oushen third level power surge protector model: PMD15-2220V PMD15-110V PMD15-24V

Product Details

Main features:
1) Electronic aging thermal detachment device, high reliability, effectively avoids short-circuit faults, can save backup short-circuit fuses or circuit breakers, reduce equipment investment, and reduce installation space;
2) The detachable lightning protection module is easy to install, and the lightning arrester can be replaced without power outage after the product ages.

installation
1. The power connection wire should be a multi stranded copper wire with an area of not less than 6mm2, and the grounding connection wire should be a multi stranded copper wire with an area of not less than 10mm2. The connecting wire should be as short, straight, and thick as possible.
2. The front end of the lightning arrester should be connected in series with suitable backup protectors, fuses, or air switches.
Installation precautions
1. During installation, the power must be disconnected and live operation is strictly prohibited. The connecting wires must meet the requirements.
2. After installation, insert the lightning protection module into place and check if it works properly.
3. The lightning arrester does not require special maintenance, it only needs to be regularly checked for loose connections and normal status indicators.
