Fully automatic sesame oil filling production line

This series of fully automatic sesame oil filling production lines adopts the principle of volumetric metering filling, suitable for filling various specifications (100ml-1000ml) of pumpkin seed oil, hazelnut oil, peony seed oil, sesame oil, walnut oil, camellia oil, flaxseed oil, cottonseed oil, olive oil, soybean oil, corn oil, rapeseed oil and other edible oils

This series of fully automatic sesame oil filling production lines adopts the principle of volumetric metering filling, suitable for filling various sizes (100ml-1000ml) of pumpkin seed oil, hazelnut oil, peony seed oil, sesame oil, walnut oil, camellia oil, flaxseed oil, cottonseed oil, olive oil, soybean oil, corn oil, rapeseed oil and other edible oils. The equipment adopts servo driven piston metering, ensuring a filling accuracy of 1 ‰. While ensuring the filling accuracy, it also increases the filling speed by 20% -35%. It is easy to operate, easy to maintain, saves labor costs, and has higher production efficiency.

Glass bottle filling machine parameters

1. Filling capacity: 100ml-1000ml

2. Filling speed: 2500-3000 bottles/hour

3. Filling accuracy: ± 0.1%

4. Electricity Flow: 3A

5. Power supply: 380V 50/60Hz

6. Skill Rate: 2.5KW

7. Qi Pressure: 0.5-0.7MPa

8. Equipment size: 2400 * 1800 * 2400 (mm) (reference size)

Filling machines require public facilities and conditions

1. Power supply: 380/220V ± 15%, 3-phase+ground wire, 50Hz

2. Compressed air: dry&clean gas, pressure 0.5-0.8MPa

3. Humidity: up to 98%

4. Environmental temperature: 0-40 degrees Celsius

5. Motor drive device: IP55

6. Electrical installation: IP54

Characteristics of filling machine

1. Vacuum suction anti drip filling head

(1) Design and vacuum suction system to ensure no dripping or leakage during the filling process, and not to contaminate the conveyor chain plate and bottle body. The filling head and cylinder adopt a separate mechanism, which can be disassembled separately and will not cause liquid leakage and damage to the cylinder. The imported Yadeke cylinder is durable, and other sealing and other accessories use standard parts, making replacement and maintenance simple and convenient.

(2) Abandoning the traditional bottle mouth filling method, a submerged filling method is adopted, filling is carried out within about 5-8mm of the barrel mouth, and the discharge port design avoids the phenomenon of small oil droplets splashing and contaminating the bottle mouth due to fast filling speed. Combined with multi-stage fast and slow filling, it can ensure full speed filling during high-speed filling, and can effectively solve the foam bottle overflow phenomenon when the air pressure is too high for fast filling. It has more variable frequency control, safer and more stable self-protection, and extends the service life of the equipment.

2. Adopting high servo control and replacing traditional pulse generators with rotary encoders, it has strong anti-interference ability and more stable overall operation. Imported programmable logic controller (PLC) and color touch screen make the filling control system more reliable.

3. Imported programmable logic controller (PLC) and color touch screen make the filling control system more reliable. Ensure stable and reliable operation of the entire machine.

4. Optimization of filling machine operation program, capable of storing more than 20 sets of formula parameters. When customers fill materials of different specifications and densities, the parameters can be pre-set and stored, and can be switched with one click during use, making the operation simpler and more convenient, while reducing the technical requirements for operators.

5. The filling adopts a motor lifting structure. When filling different specifications, the filling head height can be adjusted directly on the touch screen with one click, without the need for manual repeated positioning and adjustment, making it more convenient.

6. The frequency conversion power of the conveyor belt is separated. The filling machine and the locking machine both use separate frequency conversion power heads, which operate independently without interfering with each other and can be adjusted together by the touch screen of the main machine, ensuring stability. The start and stop of the conveyor belt are buffered to ensure smooth transportation and prevent bottle tipping and oil splashing.

7. The filling host platform adopts a unique inclined oil collection design, making cleaning more convenient and thorough.

8. The filling head is safe and reliable, and is a hose suitable for food and oily foods; Heat resistant, oil resistant, non-toxic, soft, easy to use, suitable for piping in movable parts; High transparency allows for material confirmation, ensuring peace of mind and reliability.

9. The surface is flat and smooth without dead corners, and protective plugs are installed in the nut holes to prevent dust from entering, making it cleaner and more hygienic.

Product Introduction of Bucket Lid Lifting Machine:

This lifting cover is mainly suitable for industries such as pharmaceuticals, food, chemicals, and daily chemical products, and is an ideal supporting equipment for automatic production lines such as capping machines and capping machines. Replacing traditional manual cover with bottom cover makes automation work more convenient and efficient. Especially for bottle caps that require no wear and tear, such as printed caps that need to be produced or packaged in the next step, this equipment can effectively reduce wear and tear; Its working principle is to detect the effect of micro switches, and through the conveying scraper, the bottle caps in the hopper are uniformly fed into the cap sorting machine according to production needs, ensuring that the bottle caps in the cap sorting machine can be kept in good condition;

Equipment parameters:

1. Bottle cap diameter: 20-60mm (special customization is available)

2. Cover speed: ≤ 10000 pieces/hour

3. Power supply: 220V/50Hz

4. Power: 0.37kw

5. Total weight: 150kg

6. Dimensions: 800 * 600 * 1900mm

Equipment Introduction:

The technology used throughout the machine, microcomputer PLC electronic fiber optic sensor control system, ensures stable and high-speed operation of the entire machine; The operating system adopts an operating interface control, which is easy to operate, practical, efficient, and has a production counting function; The speed of technology is fast and stable; Wide applicability, suitable for labeling circular bottles of various sizes; Adhesive rolling bottle body, making the label more firmly attached; Optional connections can be used for the front and rear sections.

Technical parameters

1. Voltage specification: AC220V 50/60HZ single-phase

2. Energy consumption power: 300W

3. Dimensions: 2000 (L) × 700 (W) × 1270 (H) mm

4. Labeling speed: 30-60 bottles/minute (labeling speed 3.5m/min)

5. Material conveying direction: left to right or customized

6. Whole machine weight: 200KG

7. Labeling accuracy: ± 1mm (excluding errors between the object being labeled and the label itself)

8. Applicable bottle type: round bottle

9. Applicable container range: outer diameter 16-120 mm, height 35-300 mm

10. Applicable label range: height 15-200mm, length 23-300mm

Machine Introduction:

The labeling machine produced by our company is suitable for various bottle types in the food and beverage industry, such as juice, tea drinks, dairy products, purified water, seasonings, beer, sports drinks, etc. Not only does it have high labeling position accuracy, but it can also highlight the bottle shape after shrinking.

2. Stable mechanical structure: The whole machine adopts stainless steel protective frame cover and aluminum alloy body frame, which is stable and rust free.

3. Flexible selection of multiple bottle types: can be fitted with round bottles, square bottles, oval bottles, bottle mouths, and bottle bodies.

4. Unique synchronous cutter holder, within the specification range, no need to replace the cutter holder. If you need to change the specifications, it can be quickly completed in 2 minutes.

5. Wide applicability: Suitable for various types of plastic and glass bottles such as food, beverages, cleaning products, medicines, and wine bottles PVC、PET、PS、 Containers such as iron cans.

6. High quality positioning accuracy: Fully mechanical transmission design, using forced labeling, suitable for various film thicknesses above 0.03mm, with adjustable inner diameter range of 5-10mm for film materials.

7. Low maintenance cost of consumables: This machine adopts low-cost disposable blades, which are easy to replace and have a low cost burden.

8. Reliable after-sales service: The machine has spare parts in various parts warehouses that can be provided at any time, and experienced engineers provide technical support for you.

9. The overall structure is sturdy, making it lighter and more flexible to use.

10. Exclusive design of reciprocating cutter, with rigid body combination of mechanism, smooth movement, and doubled tool life.

11. Simple center track pillar positioning, easy to replace specifications, convenient for operators to use, easy to understand and learn to operate, completely avoiding user confusion.

12. With a brand new structural design in the industry, the quality is more solid and outstanding, which cannot be compared with existing products.

13. The structural components of this machine are simple and generous, ensuring low failure rates and easy maintenance.
