High Resolution Metal Detector - Metal Detection Machine for Food and Drug Industry

The metal detector developed by Shanghai Qingyi manufacturer detects both iron (such as needle tips and iron filings) and non-ferrous metals (such as copper pins and stainless steel). When a metal foreign object is detected, the machine will emit a dual function alarm of sound and light, and stop running. It has high sensitivity and good stability. This metal detector is mainly suitable for detecting iron and metal foreign objects lost in products in industries such as food raw materials, additives, food, pills, candies, aquatic products, dried vegetables, frozen foods, shoes, toys, plastics, and chemicals, ensuring that products are free of metal contamination and providing reliable quality assurance

Metal detectorTechnical Specifications:

Detection hole chamber degree: 400mm Detection hole height 100mm

Main material: Made of all stainless steel (304)

Testing spirit level: In the empty state: 0.8mm in iron, 1.5mm in stainless steel SUS>medium

Belt height: 750mm (adjustable up and down by 50mm)

Conveyor speed: 25m/min

Display and operation mode: LED LCD flat key input

Power requirement: AC220V

Weight: 200KG

Machine size: 1330 × 720 × 1000mm (length × width × height)

Metal detectorfeature

Dual circuit electromagnetic wave detection: The combination of new analog circuits and digital circuits greatly improves product reliability and intelligence.

Large scale integrated circuit: The metal detection machine adopts a new type of touch screen input and is composed of large-scale integrated circuits. The CPU completes the collection of analog signals and converts them into digital quantities for processing and output. It automatically retrieves the metal content points of the detected substance, greatly improving the sensitivity and reliability of detection.

Humanized interface design: The entire operation process is simple and intuitive, and the operation interface is clear at a glance. All functions can be directly operated on the screen to complete the executed functions.

◆ Equipped with preset power and self checking function: Various required functions and modes can be set, and self checking function can be set.

◆ Adjustable sensitivity: divided into levels, adjustable to increase or decrease (1-9 levels adjustable).

Simultaneous sound, light, and instrument alarms: When trace metal is detected, the sound, light, and instrument alarms simultaneously, and the non-conforming product automatically returns to the stop state.

◆ Microcomputer computer control system: This product adopts a computer composed control system, which can complete the requirements of counting the number of detected substances, classifying and counting qualified and unqualified products, storing and printing data, identifying dry and wet concentration products, and separating multiple devices that work simultaneously and cause mutual interference according to special user requirements
