Guangdong Shenzhou Technology Co., Ltd
IP visual access control intercom extension
NegotiableUpdate on 05/08
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
Shenzhou Technology IP visual access control intercom extension, high-performance ARM main control chip, 2-megapixel high-definition camera, H.265 encoding, supports 1080P high-definition video transmission, high fidelity high volume calling, national standard GB28181 protocol, Internet of Things technology, supports cross platform intercom, supports call transfer to mobile phones, fixed telephones, and supports off network intercom.
Product Details
IP visual access control intercom extension
Shenzhou Technology IP visual access control intercom extension, high-performance ARM main control chip, 2-megapixel high-definition camera, H.265 encoding, supports 1080P high-definition video transmission, high fidelity high volume calling, national standard GB28181 protocol, Internet of Things technology, supports cross platform intercom, supports call transfer to mobile phones, fixed telephones, and supports off network intercom.
PRODUCT FUNCTION
Cross platform intercom
call forwarding
video intercom
Broadcast function
Duty Custody
Call hold
Audio and video recording
Strong insertion and strong cutting
Voice Announcements
Offline use
Product advantages
Duplex pairing
Supports duplex intercom between the host and the grading system
One click alarm
In case of danger or emergency in any usage scenario, one click call and alarm can be sent to the duty room intercom host, achieving full duplex intercom
Public Broadcasting
The on duty police officer broadcasts and educates the extension units in the management area on the video intercom host, and can also provide emergency broadcast notifications in case of emergencies
Monitoring and alarm
When the extension camera detects a concentration of people, frequent movements, climbing, or other dangerous events in the surrounding environment, it automatically pushes alarm information to the host
Product parameters
processor core ARM926@ 800MHz，32KB I-Cache，32KB D-Cache
Memory DDR3 SDRAM，128MB
storage Standard 32MB (upgradable and expandable storage space)
network interface Six standard RJ45 interface
Camera 2 million pixel full HD CMOS sensor
Video Coding Supports multiple bitstreams of H264/H265 1080P@30fps Hardware coding
working voltage DC12V（DC9V～15V）
operation temperature -20℃～60℃
External expansion interface 1 RS485 serial communication, 6 IO level or switch input, 2 IO level or DC12V power output
Suggested installation height The bottom of the equipment is about 1.4 meters above the ground
Dimensions 148x75x25.5mm
protection grade IP65
tamper device Built in anti disassembly device
Note: The same model of product may have multiple versions, and there may be differences between different versions of the product (including functional parameters, logo design, appearance details, product information, etc.). Please refer to the actual product.
Application scenarios
prison
Public places (banks)
park
