MC840DiscPro Lawn Mower Regulator

NegotiableUpdate on 03/16
Model
Nature of the Manufacturer
Producers
Product Category
Place of Origin
Overview
If you need a lawn mower regulator to quickly dry hay, Vermeer is your top choice
Product Details

If you need a lawn mower regulator to quickly dry hay, Vermeer is your best choice. The MC840 DiscPro ® The functions of steel roller regulators or spring steel wheel blades can fully meet the needs of farmers. Economic side pull MC840 with patented DynaGuard ® Swing back suspension system and our unique Quick Clip ™ The blade fixing system can cut grass with a width of up to 3.2 meters and crush or squeeze it.

Topic and Benefits

  • The cutter angle can be changed in the cab using the unique Vermeer mobile hydraulic adjustment device.
  • More efficient adjustment - with unique grooved steel rollers and patented small roller timing system, it can improve the adjustment cutting rate.
  • Choose your adjustment system - featuring unique grooved steel rollers or patented multifunctional spring steel wheel blades for cutting various crops.
  • Replacing blades extremely quickly - using the unique Quick Clip ™ The blade fixing system allows for extremely quick replacement of blades.
  • It can move between different work locations - its transport width is only slightly wider than the actual cutting width.
  • Consult a Vermeer dealer for comprehensive service and original Vermeer spare parts.

Scan the QR code and use your phone to check
No corresponding parameter group found, please add it in the backend property template
Transportation height 73.9 in 187.7 cm
Transportation width 11 ft 3.4 m
Transportation length 17.8 ft 5.4 m
Height 53.5 in 135.9 cm
Working Length 16.6 ft 5.1 m
Total weight of steel roller regulator 4420 lbs 2004.9 kg
Total weight of hook tooth adjuster 4360 lbs 1977.7 kg
Traction rod weight 1260 lbs 571.5 kg
Traction Rod - Standard couple
Drive - PTO 540 revolutions per minute
Required power 75 hp 55.9 kw
Hydraulic type 2 double acting
hydraulic pressure 1800 psi 124.1 bar
Hydraulic flow rate 6 gpm 22.7 L/min
driving cab Fully enclosed cab
Cutting width 10.5 ft 3.2 m
Cutting height - minimum 1.3 in 3.3 cm
Cutting height - maximum 6.5 in 16.5 cm
Number of cutting discs 8
Type of cutting disc Quick Clip Blade Fixing System
Cutting disc cutting diameter 19.7 in 50 cm
Blade rotation speed 167 mph 268.8 km/h
Cutting disc speed 2850 rpm
Number of blades 16
Cutter angle 0 to 10
Angle adjustment Hydraulic slope control device
Cutter sled Integrated bottom sled or modular independent bottom sled
type Composite steel roller
Regulator driver 4-Loop -5V Belt
Regulator width 96 in 243.8 cm
ROLL DIAMETER 10.3 in 26.2 cm
Roller speed 730 rpm
Minimum grass groove width 36 in 91.4 cm
Maximum grass trough width 78 in 198.1 cm
type Spring steel wheel blade
Regulator driver 4-Loop -5V Belt
Regulator width 96 in 243.8 cm
working diameter 17.5 in 44.5 cm
High hook tooth speed 933 rpm
Minimum grass groove width 36 in 91.4 cm
Maximum grass trough width 78 in 198.1 cm
tire 11L-15
Lawn mower suspension mechanical spring
safety equipment Slow signal, taillights
Torque protection Friction disc clutch
warranty One year limited warranty and three-year limited warranty for cutters

safety chain correct
platform correct
