OK-CW type infrared temperature measurement security door

1、 Scope of use

The infrared temperature measurement door is an integrated infrared temperature measurement module based on the metal detection door, used to detect the situation of personnel passing through the detection door. Compared to ordinary infrared thermometers, the temperature measurement door has relatively low power consumption, is not easily damaged, and is relatively less affected by outdoor temperature. The temperature measurement is more accurate. Once the temperature of the person being measured exceeds the set value, a "beep..." long beep alarm will be issued. There is a temperature display screen on the door, and the number of alarms and the number of people passing through it will be counted, which can effectively avoid close contact between the thermometer and the person being measured, reduce the potential risk of virus infection, and can be widely used in large places such as residential areas, stations, schools, docks, airports, etc.

2、 Functional Features

1. Low power consumption, small size, single location continuous and precise alarm;

2. Infrared temperature measurement with metal security check: Organic fusion of infrared temperature measurement and metal security check, passing through the metal security check door

Before proceeding, conduct infrared human body temperature measurement, and sound an alarm with a human voice to indicate abnormal body temperature, effectively preventing scale issues

Sexually transmitted diseases;

3. Factory calibration has been performed within a wide temperature range: sensor temperature -40 to 125 ° C, object temperature -70 to 380 ° C

4. The accuracy can reach up to 0.5 ° C within a wide temperature range (both Ta and To have a temperature range of 0...+50 ° C);

Medical precision measurement resolution of 0.02 ° C can be achieved within a limited temperature range of 0.1 ° C upon request

3、 Technical parameters

1. Operation method: panel numerical key operation; Manual button operation; Digital panel display;

2. Detection area: The detection gate is divided into multiple overlapping detection areas based on the basic structure of the human body, using a mesh detection method

The measurement method and single frequency excitation technology eliminate weak and blind areas within the detection area, resulting in higher sensitivity and more stable performance.

3. Alarm mode: Sound and light alarm, tone speed can distinguish the size of metal objects, multiple alarm volume modes are suitable for different occasions

The selection can accurately display prohibited items hidden at the corresponding height of the human body through the ultra bright LED alarm lights on both sides of the door post.

4. Temperature measurement alarm: Real person voice alarm, indicating abnormal body temperature; Having a temperature compensation menu, the compensation value can be adjusted, and the screen will always display the last test temperature. After the person leaves the probe, the temperature will continue to be displayed on the screen;

5. Regional sensitivity: It can detect metal content objects the size of paper clips (customized), and can be adjusted between 0-99 levels of sensitivity. The adjusters in each area can be adjusted to the appropriate sensitivity according to the detection requirements, and the overall sensitivity can be adjusted separately. Pre set the weight, volume, size, location, and exclude false alarms for metal items such as keys, jewelry, belt buckles, etc.

6. Intelligent statistics: The intelligent passenger flow and alarm counting function can automatically count the number of people passing and the number of alarms.

Strong anti-interference ability: using digital, analog, and left-right balancing technologies to prevent false alarms and missed alarms, greatly improving anti-interference ability.

4、 Equipment configuration

1 instrument host, 1 instrument user manual, 1 inspection certificate, 1 instrument warranty card, 2 fuses (Φ 5 × 20), 1 roll of thermal printing paper, and 1 power cord.
