Realistic view of an eight station rotary screen printing machine factory

Independent research and development brand - Eight station screen printing machine

Product performance
1. Adopt imported PLC combined with switch button panel to control and compile action program
2. Automatic passive counter, constantly displaying production quantity and counting printing efficiency
3. Fully cast aluminum body, surface sandblasted and oxidized
4. Double column lifting structure, stable and high-precision
5. Adjustable left and right travel, Taiwan photoelectric switch limit
6. The angle of the scraper/ink return knife can be adjusted freely
7. Scraper constant pressure device to ensure stable pressure during the printing process
8. Adjust the rotation angle of the workbench from front to back, left to right, and lock it in place
9. The position of the mesh frame can be adjusted back and forth, left and right, horizontal, and high and low
10. Equipped with Taiwanese hydraulic buffers up, down, left, and right to eliminate printing vibrations,
11. The whole machine runs fast, smoothly, and with low noise
Scope of application
Especially suitable for printing surface patterns on lenses, buttons, PVC film, paper, stationery, mobile phone lenses and other small plastic products, electronic remote controls, calculators, insoles, rulers, acrylic sheets, glass, phone cases, etc.
Technical Specifications:
Machine model: SKR-ZP1520 Machine name: Eight station rotary screen printing machine
Up and down drive mode: pneumatic, left and right drive mode: pneumatic
Left and right stroke: 180mm Up and down stroke: 150mm
Mesh frame size: 300 * 450mm Chassis area: 150mm250mm
Workbench area: 150 * 200mm Printing area: 150 * 100
Workpiece height: 100mm Printing stations: 2, 4, 6, 8 available for selection
Printing speed: 2000-2200 times/hour Power requirement: 220V 50/60HZ 550W
Air pressure: 5-7 BAR
