Shenyang Boneng Explosion proof Mobile Handheld Phone - BN3050

NegotiableUpdate on 05/17

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

Dimensions: 195mm * 76mm * 28mm Operating frequency: ultra-high frequency: UHF 900MHz Reading and writing Operating voltage: 7.4V Operating temperature: -20 ℃ to 50 ℃

Product Details

overview
performance parameter
Product Features
Documents
Project application

◆ 5-inch high-definition high brightness 720P display screen, meeting the requirements of outdoor operations; Support the full network standard;

Flexible circuit design provides customized and customized services to meet the needs of different users;

The device integrates multiple data collection functions and wireless communication, with reliable performance and simple operation;

IP65 protection level, achieving a high degree of uniformity in performance and durability;

Innovative designs that conform to ergonomics and user-friendly interfaces can maximize work productivity;

Explosion proof products, widely used in the petroleum and petrochemical industry (★ special models).

Basic Product Information
CPU	Cortex-A53 1.5GHz quad core
storage	RAM 2G、ROM 16GB;
operating system	Android 5.1
User storage expansion	Micro SD Card compatible with 128GB
keyboard	22 keys+power key (LED keyboard backlight)
display screen	5.0”IPS LCD， Resolution 720p (1280 * 720), capacitive touch screen, LED backlight
Battery capacity	2600mAh 7.4V (DC dedicated charger 9V voltage, 1.2A current)
Wireless transmission method	1. Bluetooth v2.1+ EDR/ V3.0+ HS/ V4.1 2. WIFI 802.11 b/g/n/a 2.4G/5G 3. GPRS/HSPA/EDGE/CDMA2000/TDD/FDD
Notification method	Sound, vibration, LED prompts
audio	Built-in speaker
Camera	8 million effective optical pixels (autofocus; supports flash, flashlight)
work environment	Normal operating temperature: -20 ℃ to 50 ℃; Low temperature battery: -30 ℃; Low temperature battery: -30 ℃
protection grade	IP65
Drop Test	Within the operating range, all six sides can withstand the impact of falling from a height of 1.5 meters to a cement floor
Rolling test	Rolling specification 1000 times 0.5 meters, 6 contact surfaces rolling
Electrostatic discharge（ESD）	± 15kV air discharge, ± 8kV direct discharge
Explosion proof grade	Ex ib IIC T4 Gb (specific model)
Equipment size	195mm76mm28mm； Weight (350g)
gsm	Dual SIM dual standby, 4G full network connectivity
communication module	4G TDD-LTE : 1900/2300/2500/2600 MHz(B38/B39/B40/B41) 4G FDD-LTE : 1800/2100/2600 MHz (B1/B3/B7) 3G TD-SCDMA: 1900/2100 MHZ (B34 B39 ) 3G WCDMA:850/900/1900/2100 MHz(B1 B2 B5 B8) 2G GSM:850/900/1800/1900 Mhz(B2 B3 B5 B8) CDMA&EVDO: 800 MHz(BC0)
Communication speed	FDD: 150Mbps downstream and 50Mbps upstream TDD: 150Mbps downstream and 50Mbps upstream WCDMA HSDPA: 42.2Mbps downstream and 11.5Mbps upstream TD-SCDMA: downstream 384Kbps, upstream 384Kbps TD-HSDPA: downstream 2.2Mbps, upstream 2.8Mbps CDMA2000 1xRTT ： 153.6Kbps CDMA 2000 HRPD/1xEV DO: Forward Link 3.1Mbps Reverse Link 1.8Mbps
Scalability (optional according to customer needs)
physical interface	Micros SD/TF card slot, SIM card slot, 2 PSAM card slots Micro USB interface, headphone interface
RFIDrfid	Ultra high frequency: UHF 900MHz read and write support EPC C1 GEN2/ISO18000-6C protocol tag processing speed>200 tags/second, maximum reading distance 5M
GPS positioning module	GPS，AGPS，BEIDOU Positioning accuracy<10 meters Positioning time<40s
accessory	USB data cable, dedicated charging adapter, single battery; Backup battery (optional), charging dock (optional)
