Songqin Co., Ltd
Submicron high-efficiency forming flat grinding machine SGE series
NegotiableUpdate on 09/09
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
The minimum setting unit is 0.1 μ m
Product Details
- The minimum set unit is0.1μm.
- According to the needs, all options can be selected to complete mirror flat processing, groove processing, contour grinding processing, and row grinding processing.
|
Machine capability |
|||
|
SGE 515 |
SGE 520 |
SGE Nero3 |
|
|
Electromagnetic clamp size |
500mmx150mm |
500mm x 200mm |
500mm x 200mm |
|
Workbench movement amount (Left and right x front and back) |
580mm×170mm |
650mm×230mm |
650mm×230mm |
|
Distance from the top of the workbench to the center of the spindle |
370mm |
470mm |
470mm |
|
Minimum upper and lower setting units |
0.1μm |
0.1μm |
0.1μm |
|
Minimum setting unit before and after |
0.1μm |
0.1μm |
0.1μm |
|
Grinding wheel size (Outer diameter x Width x Inner diameter) |
φ180~255mm×8~19mm ×φ31.75mm |
φ180~255mm×8~19mm ×φ50.8mm |
φ180~255mm×8~19mm ×φ50.8mm |
The above specifications may vary due to the manufacturer's improved model, and the actual specifications quoted by our company shall prevail. For detailed specifications, please feel free to contact our company
