Tomato Sauce and Chili Sauce Automatic Filling Machine

Tomato Sauce and Chili Sauce Automatic Filling Machine

Product Introduction
It mainly consists of a 10 head filling machine, a linear capping machine, a vertical round bottle labeling machine, and a bottle feeding turntable. Imported PLC program control, 304 stainless steel is used for liquid contact parts such as filling nozzles and material troughs, and PTFE is used for sealing rings. Suitable for slurry filling in food, pharmaceutical, daily chemical, chemical and special industries.
Technical parameters of 10 head filling machine:
Number of filling heads: 10
Filling capacity: 0.1L~0.5L
Filling form: piston filling
Filling speed: 50-60 bottles/hour (450 milliliters)
Filling accuracy: ± 1% Air pressure: 0.5-0.8MPa
Conveyor belt: 82mm POM chain belt
Drive motor: 550W variable frequency speed regulating motor
Power: 1KW/380V three-phase five wire
Technical parameters of linear bottom cover machine:
Applicable bottle cap diameter: 50-60mm
Capping speed: 50-60 bottles/minute
Liding Method: Magnetic Conveyor Belt for Liding and Liding
Technical parameters of linear capping machine:
Applicable bottle width: 40-90 millimeters
Applicable bottle cap diameter: 30-60 millimeters
Production capacity: 50-60 bottles/minute
Cap motor: 550W
Technical parameters of vertical round bottle labeling machine:
Rated voltage: 220V/50HZ
Whole machine power: 500W
Whole machine weight: 146Kg
Dimensions: 1710 × 950 × 300 (millimeters) (length × width × height)
Labeling accuracy: ± 1mm
Applicable label range: Height 10-100 (millimeters), Length 10-300 (millimeters)
Production capacity: 60-150 bottles/minute (depending on bottle diameter)
