Tubular atmosphere furnace
NegotiableUpdate on 01/08
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
Main functions and features of tubular atmosphere furnace: 1. The furnace is made of high-quality alumina fiber material, which has good insulation performance, durability, high tensile strength, no impurities, high purity, and obvious energy-saving effect; $r$n 2、 The heating element adopts high-quality HRE resistance wire, greatly improving its service life; $r$n 3、 Overtemperature alarm, leakage protection, safe and reliable operation.
Product Details
Our company has over 15 years of experience in the field of high-temperature electric furnaces. Our main products include: box furnaces, atmosphere furnaces, tube furnaces, crucible furnaces, lifting furnaces, trolley furnaces, dental denture furnaces, crystal growth furnaces, vacuum furnaces, graphite furnaces, rubber extrusion furnaces, and other high-temperature equipment ranging from 300 ° C to 3000 ° C. We can also provide various non-standard customizations with reasonable solutions
Tubular atmosphere furnaceMain functions and features:
1. The furnace is made of high-quality alumina fiber material, which has good insulation performance, durability, high tensile strength, no impurities, high purity, and significant energy-saving effect;
2. The heating element adopts high-quality HRE resistance wire, greatly improving its service life;
3. Overtemperature alarm, leakage protection, safe and reliable operation.
Tubular atmosphere furnaceMain purpose and scope of application:
Used for high-temperature atmosphere sintering, atmosphere reduction, CVD experiments, vacuum annealing, etc. in universities, research institutes, and industrial and mining enterprises.
Technical Specifications:
| maximum temperature | 1200℃ |
| Common operating temperature | Below 1100 ℃ |
| heating element | resistance wire |
| Heating method | Double sided heating |
| thermocouple | K-type |
| Temperature control accuracy | ±1℃ |
| Working Voltage | 220V/2KW |
| Design | The electric furnace adopts a humanized design, which is beautiful and easy to operate. The outer paint layer uses spray coating and high-temperature baking technology. Has high temperature resistance, oxidation resistance, and acid alkali resistance. |
| Shell design | The electric furnace shell adopts a double-layer forced air cooling structure, which makes the external temperature of the furnace shell close to room temperature at high temperatures, avoiding accidental injuries. |
| Furnace structure | Integrated compact design, stepped splicing structure, in accordance with the laws of mechanics, uniform force during heating, ensuring that heat energy is not easily lost and extending the service life of the furnace. |
| Furnace material | The furnace material adopts advanced lightweight alumina ceramic fibers, which have excellent insulation effect, light weight, high temperature resistance, extreme cold and heat resistance, are not easy to crack, crystallize, and fall off, so there is no need to worry about polluting the fired products. The energy-saving effect is 60% -80% of that of old-fashioned electric furnaces. |
| temperature control | Adopting intelligent temperature control instruments from domestic Yudian instrument manufacturers, it can set 30 segments of intelligent programmable PID self-tuning, with one click operation, automatic heating and cooling, no need to keep the value, and simple and convenient operation. |
| heating rate | 0-20 ℃/min can be set arbitrarily, it is recommended to be ≤ 10 ℃/min |
| safety protection | The electric furnace adopts integrated circuits and module control (With protection functions such as temperature deviation protection, over temperature protection, couple breaking protection, over-current protection, etc.) ensures stable, reliable, and safe operation of the electric furnace. |
| Gas permeable | All inert gases, mixed gases, nitrogen, oxygen, carbon monoxide, argon, etc. |
| Gas control | One intake port can be set at the intake end, and multiple intake ports can be optionally configured. Each intake port is equipped with a needle valve and connected to a vacuum gauge. Connect one air outlet and one vacuum hole to the exhaust end, and install needle valves for all holes. Equipped with one vacuum pump. |
| ultimate vacuum | -0.1mpa |
| Sealing method | Adopting 304 stainless steel flange, it has the advantages of easy loading and unloading, oxidation resistance, acid and alkali resistance, double-layer sealing, ensuring sealing performance. |
| warranty period | Furnace body warranty for one year (excluding vulnerable parts of heating element), lifetime maintenance |
| Standard Accessories | One vacuum pump, one crucible hook, one pair of heat-resistant gloves, one user manual, certificate of conformity, and warranty card. |
| Product Certification | This product has passed the EU standard CE certification and ISO 9001:2015 quality management system certification |
| packaging | The export wooden case is packed with foam filled inside, and the furnace body is wrapped with plastic film. |
