XMRD70 series guided wave radar level/material level gauge

NegotiableUpdate on 12/16

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

1、 Measurement principle: The high-frequency microwave pulse emitted by the guided wave radar propagates along the detection component (steel cable or steel rod) and encounters the measured medium. Due to a sudden change in dielectric constant, it causes reflection, and a portion of the pulse energy is reflected back

Product Details

1、 Measurement principle

original Reason:

The high-frequency microwave pulses emitted by the guided wave radar propagate along the detection component (steel cable or steel rod) and encounter the measured medium. Due to a sudden change in dielectric constant, reflection occurs, and a portion of the pulse energy is reflected back. The time interval between the emitted pulse and the reflected pulse is proportional to the distance of the measured medium.

special Point:

Due to the use of advanced microprocessors and unique featuresEcho Discovery echo processing technology and guided wave radar level gauges can be applied to various complex working conditions.

Multiple process connection methods and types of detection components enableThe 70X series guided wave radar level gauge is suitable for various complex working conditions and application scenarios. Such as high temperature, high pressure, and low dielectric constant media.

Adopting a pulse working mode, the guided wave radar level gauge has an extremely low transmission power and can be installed in various metal and non-metal containers without harming the human body and the environment

2、 Product Introduction
