ZY series IoT fire booster water supply equipment

NegotiableUpdate on 05/13

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

The design of ZY series fire pressure boosting water supply equipment fully draws on emerging technologies and mature experience in municipal water supply in recent years, and combines the development of Internet of Things technology in recent years to develop and produce a new type of multi-functional integrated, well applicable, safe and reliable fire extinguishing facility. Two fire pumps form a unit (one in use and one backup), which can also be expanded to three fire pumps form a unit (dual-use and one backup) or four fire pumps form a unit (three in use and one backup) according to actual working conditions.

Product Details

Characteristic Value

Automatic inspection

All pump units can be automatically inspected in sequence, or the inspection scope, inspection cycle, and inspection duration can be set according to actual needs.

Manual inspection

It is possible to manually inspect the pump in the control system

Mechanical emergency start

When the electronic control system malfunctions or undergoes system maintenance, in the event of a fire, the mechanical emergency starting device can be used to forcibly start the pump unit

Fire protection (fire linkage) linkage

In case of a fire, the system automatically starts the pump unit, displays the fire signal in the system, and can push the information to the remote terminal

Fault Alarm

When there is a malfunction or abnormal pressure, the host will automatically sound an alarm

mobile terminal

Real time intelligent real-time operation data can be viewed on mobile devices such as smartphones and computers, and historical operation records can be exported on computer terminals

Hand/automatic conversion function

Local start stop function, mechanical forced start stop function

IoT interface

The control system is equipped with a gateway interface for uploading operational data from the local control system to the data management platform

Automatic end water testing interface (optional)

During the inspection process, close all intelligent end water testing devices and intelligent water testing valves; When the host experiences communication failure, all end water testing devices can be turned off with one click

IoT functionality

Project information collection and operational data collection

scope of application

Suitable for fire water supply systems in industrial buildings (such as factories, warehouses, storage tanks, yards, etc.), civil buildings (such as stations, airports, hospitals, offices, commercial buildings, garages, exhibition buildings, cultural and sports buildings, cinemas, residential buildings, urban complexes, etc.), and other engineering projects
