ZYK-01KH Fully Automatic Paper Box Forming Machine (Aircraft

Technical Specifications:

1Equipment adoptionSiemensPLC、SiemensTouch screen, Mitsubishi inverter,KEYENCESensors, Schneider Electric components, Taiwan Shengbang Motors, etc;

2The equipment frame is constructed with aluminum profiles, which have a beautiful appearance and greatly reduce the weight of the equipment;

3All components of cylinders, solenoid valves, and vacuum generators are made of the Yadeke brand;

4Ball screws, linear guides, etc. are all made in TaiwanHIWINWaiting for brands;

5Single station equipment is equipped with casters and a lifting tripod, which facilitates the movement and fixation of the equipment; The gas source adopts a quick connect plug;

6Installation materials, power and control cables: well-known brands (such as Far East, Nanyang, Baosheng, etc.), cable installation tray: well-known brands, strong and weak current separation fasteners:8.8Grade.

7Equipment capacity:6-8Just a box/minute

8Electricity: Three phase380V 50HZ+Grounding, power capacity:5KVA

9Compressed air: pressure ≥0.5Mpatraffic>50L/min

10Applicable paper box size for unboxing machine equipment:L200-400*W200-400*H35-75MM

11Equipment size: (approximately)L1850 X W1300 X H2000mm

12Equipment weight: (approximately)1500kgPlease refer to the actual situation for details;

13The stability of the equipment system, as well as the mechanical and electrical stability itself, should be ensured99%.

14Number of paper boxes that can be stored in one device:350Zhang(Estimated thickness of cardboard box2mmunder the circumstances)；

15Equipment system andPLCLeave a certain amount of installation space and system expansion functions;

16The supply and layout of electricity and gas around the device need to be solved by the customer themselves, as well as electricity/The gas needs to be connected to the designated installation location of the equipment.
