Contact information for manufacturers of high and low temperature test chambers

NegotiableUpdate on 02/19

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

The brand new European and American explosion-proof handle designed by Shenzhen Ruitaier High and Low Temperature Test Chamber manufacturer features a perfect design, high-quality appearance, imported multifunctional, and highly expandable dedicated controller. It is easy to operate, learn, control stably and reliably, and can provide dual temperature, humidity, and low temperature tests. If you want to learn more, please continue reading below

Product Details

The brand new European and American explosion-proof handle designed by Shenzhen Ruitaier High and Low Temperature Test Chamber manufacturer features a perfect design, high-quality appearance, imported multifunctional, and highly expandable dedicated controller. It is easy to operate, easy to learn, stable and reliable in control, and can provide dual temperature, humidity, and low temperature testing. If you want to learn more, please continue reading below.

高低温试验箱厂家联系方式

1. Ultra wide temperature and humidity control range of 20% RH-98% RH
2. Comprehensive safety protection to ensure the safety of the machine itself and its users.
3. The high and low temperature test chamber adopts full capillary tube and automatic load capacity adjustment system technology, which is more stable and reliable than previous expansion valve systems. More precise temperature control, fast, stable, and even temperature rise and fall speed, saving valuable time for users.
4. Special forced air circulation design can avoid dead corners of airflow inside the box, ensuring excellent temperature distribution uniformity.
5. The design of the circular arc inner box structure is convenient for cleaning.
6. The high and low temperature wet heat alternating test chamber adopts the green and environmentally friendly (HFC) refrigerant R404A R23 with zero ozone coefficient
7. Can be connected to a computer, can be connected to 232 or USB, 485 port, and remotely controlled

Technical parameters:

Equipment model Studio size (d × w × h) mm External dimensions (d × w × h) mm

RTE-101B-l 450×450×500 1160×1000×1610

RTE-225B-l 500×600×750 1210×1150×1870

RTE-504B-l 700×800×900 1260×1340×2070

RTE-800B-l 800×1000×1000 1370×1550×2170

RTE-1000B-l 1000×1000×1000 1560×1550×2170

Temperature range: a: -20 ℃~150 ℃ b: -40 ℃~150 ℃ c: -60 ℃~150 ℃ d: -70 ℃~150 ℃

Temperature uniformity: ≤ 2 ℃ (when unloaded)

Temperature fluctuation: ± 0.5 ℃ (when unloaded)

Heating rate: 1.0-3.0 ℃/min

Cooling rate: 0.7-1.0 ℃/min

Time setting range: 1 to 9999h

Test hole: installed on the left side of the machine, used for external testing of power or signal lines

Observation window: 210 × 275mm or 395 × 395mm (effective field of view)

Outer box material: high-quality A3 steel plate with electrostatic spraying

Inner box material: imported stainless steel SUS304

Thermal insulation material: rigid polyurethane foam+glass fiber

Temperature controller: Korean ternary ST590 instrument

Temperature sensor: Pt100 platinum resistance thermometer

Cooling method: single machine or double machine stacked cooling

Compressor: Taikang from France

Standard configuration: 2-layer sample rack, equipped with a condensate water tray, and discharged outside the box

Safety protection: compressor overheating, overpressure, overtemperature, fan motor overheating, overall equipment under/reverse phase, overall equipment timing, leakage protection, overload and short circuit protection

Power supply voltage: AC380V ± 10% 50Hz

Power: (a) 3.5kw/4.0kw/6.0kw/8.0kw/9.0kw

(b)4.0kw/4.5kw/7.5kw/9.0kw/10.5kw

(c)4.5kw/6.5kw/9.0kw/13.0kw/13.0kw

Usage environment: 5 ℃~+28 ℃ ≤ 85% RH

High and low temperature test chamber manufacturer's after-sales service contact information:

Shenzhen Ruitaier test box manufacturer conducts regular follow-up visits, listens to customer suggestions, and establishes customer service files;
We provide lifelong maintenance, free technical support, and usage guidance services. You only need to call our national unified service consultation hotline or send your questions to our service mailbox at @ 163.com, and our relevant departments will contact you in the quickest way possible;
Our company promises to respond to customer calls within 1 hour. If technical service personnel need to be sent to the site for resolution, we promise to send personnel within 24 hours (except for special circumstances such as statutory holidays).
