Electronic cigarette six head oiling machine

NegotiableUpdate on 02/19

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

Six head oiling machine, high-precision thick oil fume bomb and atomizer, semi-automatic six head oiling machine adopts replaceable fixture method for oiling, with heating function suitable for various types of atomizers, e-liquids, CBD oils, THC oils

Product Details

Six head oiling machine

Six head oiling machineHigh precision range hood and semi-automatic atomizerSix head oiling machineUsing replaceable fixtures for oil injection, with heating function suitable for various types of atomizers and e-liquidsCBDOilTHCOil. The oil injection machine is easy to operate,3Editing the oil injection path of the atomizer can be completed in just one step, and most employees can operate it by familiarizing themselves with the equipment functions.

Applicable products:

Six head oiling machineThe model is compatible with smoke cartridges, atomizers, and other devices of varying lengths, as long as different fixtures are replaced; Most of them are compatible.

Six head oiling machinename	semi-automaticSix head oiling machine
Six head oiling machinemodel	RTE-360 ZY06
Effective travel (X manual adjustment/Y/Z) axis	*100300100(mm)*
Work efficiency (related to oil concentration and injection volume)	2500-3600 units/hour (2-0.3ml)
Oil injection accuracy	±1.5%
maximum speed	Y-axis: 500mm/sec, Z-axis: 300mm/sec
precision	±0.05mm
Drive mode	Stepper motor+guide rail/screw
control system	PLC+touch screen
Panel control	Touch screen+buttons
Interface control	Oil injection position adjustment, oil injection amount adjustment, speed adjustment, program selection
Max load	Workbench: 8kg Z-axis: 8kg
Program capacity	Can store 10 sets of oil injection paths
Power supply (optional)	AC220V/110V
*Dimensions W D * H (mm)/Weight**	*520 730 * 830mm/approximately 52kg**
*Including dimensions of wooden box W D * H (mm)/weight**	*570 800 * 970mm/approximately 70kg**

电子烟六头注油机
