TSI airflow hood 9565A multifunctional ventilation tester from the United States
NegotiableUpdate on 01/29
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
Brief description: The American TSI airflow hood 9565A multifunctional ventilation tester 9565 multifunctional ventilation meter is a powerful handheld multifunctional ventilation testing instrument that adds the function of a Chinese menu. The direct reading menu facilitates setting, operation, and on-site calibration. The instrument is ergonomically designed and provides keyboard locking function to prevent accidental operation. High precision testing of wind speed, Z can display 5 parameters simultaneously. At the same time, multiple pluggable probes are provided for users to choose conveniently.
Product Details
Detailed Introduction
TSI airflow hood 9565A multifunctional ventilation tester from the United States
The 9565 multifunctional ventilation meter is a powerful handheld multifunctional ventilation testing instrument with a Chinese menu display function,The direct reading menu facilitates setting, operation, and on-site calibration. The instrument is ergonomically designed and provides keyboard locking function to prevent accidental operation. High precision testing of wind speed, capable of displaying up to 5 parameters simultaneously. At the same time, multiple pluggable probes are provided for users to choose conveniently.It can display detection items such as wind speed, temperature, and humidity. The wind speed probe is solidified on a ceramic core, which is sturdy and durable, and can effectively prevent damage to the wind speed probe from sand and dust in the wind,The telescopic rod of the fixed wind speed probe is marked with a scale, which is verySuitable for fresh air volume detection of central air conditioning fresh air ducts.
TSI airflow hood 9565A multifunctional ventilation tester from the United StatesCharacteristics and advantages
Equipped with 964 plug-in wind speed, temperature and humidity probes (using thermoelectric wind speed principle)
Testing items: temperature, humidity, wind speed
Chinese interface
Simultaneously display 5 parameters
Data storage for 39 days (storage interval of one minute)
Bluetooth communication for data transmission or remote transmission
The wind speed probe is fixed on the ceramic core
The telescopic rod of the fixed wind speed probe is marked with a scale
TSI air hood from the United Statesapplication area
HVAC testing and balancing of clean spaces - Biosafety cabinet and fume hood testing
HVAC project and investigation IAQ investigation thermal comfort research ventilation system evaluation
Product parameters
| display | The anemometer method and pitot tube method meet the requirements of the national standard |
| probe | Plug in 964 wind speed, temperature and humidity probe, solidified on ceramic core, sturdy and durable. The telescopic rod of the fixed wind speed probe is marked with a scale, which can accurately locate it |
| display | Chinese interface, easy to operate |
| range | Airflow: product of 0-50m/s and pipeline cross-sectional area (directly display airflow) |
| software | Equipped with data analysis function |
| Data Storage | 26500 data points |
| Other functions | Statistical function, displaying instantaneous, average, maximum and minimum values |
TSI air hood from the United States9565 series optionalprobe
| Wind speed, temperature and humidity probes | number | Range of measurement | accuracy | resolution |
| Bend probe | 962 | windfast：0～50m/s temperature：-18～93℃ | Reading of±3%Or ±0.015m/sTake the larger one ±0.3℃ | 0.01m/s 0.1℃ |
| 966 | wind speed：0～50m/s temperature：-10～60℃ humidity：0～95%RH | Reading of±3%Or ±0.015m/sTake the larger one ±0.3℃ ±3%RH | 0.01m/s 0.1℃ 0.1%RH | |
| Straight probe | 960 | wind speed：0～50m/s Temperature:-18～93℃ | Reading of±3%perhaps±0.015m/sTake the larger one ±0.3℃ | 0.01m/s 0.1℃ |
| 964 | wind speed：0～50m/s Temperature:-10～60℃ humidity：0～95%RH | ± of reading3%Or ±0.015m/sTake the larger one ±0.3℃ ±3%RH | 0.01m/s 0.1℃ 0.1%RH | |
| Impeller wind speed and temperature probe | number | Range of measurement | accuracy | resolution |
| 995 | wind speed：0.25～30m/s temperature：0～60℃ | Reading of± 1% or ± 0.02m/s ±0.1℃ | 0.01m/s 0.1℃ | |
| Wind speed and temperature probe | number | Range of measurement | accuracy | resolution |
| 496 | Wind speed:0.5～15.00m/s Temperature:0～60℃ | ±3%±0.02m/s ±1℃ | 0.01m/s 0.1℃ | |
| Air quality probe | number | Range of measurement | accuracy | resolution |
| 980 | CO2：0～5000ppm temperature：-10～60℃ humidity：5～95%RH | Reading of±3%Or ±50ppmTake the larger one ±0.3℃ ±3%RH | 1ppm 0.1℃ 0.1%RH | |
| 982 | CO：0～500ppm CO2：0～5000ppm temperature：-10～60℃ humidity：5～95%RH | Reading of±3%Or ±3ppmTake a larger oneof Reading of±3%Or ±50ppmComparingBig one ±0.6℃； ±3%RH | 0.1ppm 1ppm 0.1℃ 0.1%RH | |
| VOCprobe | number | Range of measurement | accuracy | resolution |
| 984 | VOC:10～20000ppb temperature：-10～60℃ | ±0.5℃(±1.0℉) | 10ppb 0.1℃（0.1℉） | |
| 985 | VOC:1～2000ppm temperature：-10～60℃ | ±0.5(±1.0℉) | 10ppm 0.1℃（0.1℉） | |
| 986 | VOC：10～20000ppb CO2：0～5000ppm temperature：-10～60℃ humidity：5～95%RH | ± 3% or 50ppm,Whichever is greater ±1.0℉(±0.5℃), ±3%RH | 10ppb, 0.1ppmCO2 0.1℃ 0.1%RH | |
| 987 | VOC：1～2000ppm, CO2 ：0～5000ppm temperature：-10～60℃ humidity：5～95%RH | ± 3% or 50ppm,Whichever is greater ±0.5℃(±1.0℉), ±3%RH | 10ppm 0.1ppmCO2 0.1℃ 0.1%RH |
