Ultra thin EFU

Description: Function: Features: ◆ Lightweight

◆ Lightweight, easy to install, can be installed horizontally or vertically
◆ Low vibration, low noise, low energy consumption, low cost, can reduce costs for customers
Advanced FFU box internal structure design to improve efficiency and reduce noise, using high-efficiency, low resistance, zero leakage and high-efficiency filter media
◆ Unique internal diffuser plate, uniform wind pressure diffusion, stable and even wind speed on the outlet surface
◆ Ultra thin form, with a minimum thickness of 130mm
◆ Can be widely used in clean rooms, clean workbenches, manufacturing equipment, process assembly lines, and dust-free wardrobes
The intelligent FFU control system enables monitoring of individual and group FFUs, providing suitable FFU control methods and monitoring systems for both small-scale specific needs and large-scale integrated system requirements

model	HK-FFU-B1	HK-FFU-B2	HK-FFU-B3	HK-FFU-B4
Dragon bone size	2′x 2′	2′x 4′	3′x 4′	4′x 4′
Box size (mm)	575x575x115/WxLxH	575x1175x115/WxLxH	875x1175x115/WxLxH	1175x1175x115/WxLxH
Filter size (mm)	570x570x50/70	570x1170x50/70	870x1170x50/70	1170x1170x50/70
air volume	400~700CMH	720~1200CMH	1140~1500 CMH	1260~2100CMH
noise	48~54dB(A)	48~54dB(A)	50~56dB(A)	52~58dB(A)
Fan full pressure	140Pa	140Pa	150Pa	150Pa
power consumption	115W	115W	230W	230W
weight	15kg	20kg	32kg	42kg
material	Steel plate baking paint/aluminum zinc plated plate/stainless steel/aluminum baking paint
power supply	Single phase 110V/220V 50HZ/60HZ
Speed regulation function	Single stage speed regulation/three-stage speed regulation/stepless speed regulation/variable voltage stepless speed regulation
Filtering effect	HEPA 0.3um above 99.99%/ULPA 0.12um above 99.999%
work status	Power indicator switch operation and fault indicator light
overload protection	Dual overload protection switch for motor and controller
wiring method	Terminal block/male and female connectors/power cord
Monitoring contact point	Reserved operation and fault dry contacts
optional	Can be equipped with abnormal indoor fault LED lights, differential pressure gauges, wind speed sensors DOP、 Dismantling frames, etc
