Beijing Guance Instrument GESTD-B GESTD-B Dielectric Constant High Frequency Tester Price

GCSTD-B dielectric loss tester

Dielectric constant tester

Meet the standard: GBT 1409-2006 Recommended method for measuring the permittivity and dielectric loss factor of electrical insulation materials at power frequency, audio frequency, and high frequency (including meter wave wavelength)

1、 Overview

Dielectric loss and dielectric constant are important physical properties of various ceramics such as electrical ceramics, device ceramics, capacitors, and composite materials. By measuring the dielectric loss tangent tan δ and dielectric constant (ε), various factors affecting dielectric loss and dielectric constant can be further understood, providing a basis for improving material performance; The basic principle of the instrument is to use high-frequency resonance method and provide universal, multi-purpose, and multi range impedance testing. It uses a single-chip computer as the control of the instrument, and the measurement core adopts frequency digital locking, automatic setting of standard frequency test points, automatic search for resonance points, automatic conversion of Q value range, numerical display and other new technologies. It improves the tuning circuit, reduces the residual inductance of the tuning test circuit, and retains the automatic amplitude stabilization technology in the original Q meter, making the new instrument more convenient to use and the measurement values more accurate. The instrument can measure the Q value of high-frequency inductors or resonant circuits, the inductance and distributed capacitance of inductors, the capacitance and loss tangent of capacitors, the high-frequency dielectric loss of electrical materials, the effective parallel and series resistance of high-frequency circuits, and the characteristic impedance of transmission lines under high testing frequency conditions.

This instrument is used for applied research on the properties of inorganic non-metallic new materials in scientific research institutions, schools, factories, and other units.

2、 Technical indicators

1. Dual scan technology - dual scan and automatic tuning search function for testing frequency and tuning capacitance.

2. Dual test element input - both the test frequency and tuning capacitance value can be entered through digital buttons.

3. Dual digitalization tuning - digitalization frequency tuning, digitalization capacitance tuning.

4. Automated measurement technology - automatically measure the Q value, resonance point frequency, and capacitance of the test piece.

5. Full parameter LCD display - digital display of main capacitance, inductance, Q value, signal source frequency, and resonant pointer.

6. DDS digital direct synthesis signal source - ensuring high fidelity, high frequency, and high amplitude stability of the signal source.

7. Computer automatic correction technology and test circuit optimization - reduce the residual inductance of the test circuit to, completely eliminating the confusion of Q reading values needing to be corrected at different frequencies.

8. Users can test the quality of the device at any frequency and any point tuning capacitance value provided by the instrument, without needing to pay attention to the range and conversion units.
