M3.1-1020 Solid Wood CNC Cutting Machine

solid woodCNC cutting machineIt is a CNC automation equipment used for cutting irregular shapes of solid wood panels. It uses a milling cutter to rotate and cut the panels at high speed, forming them in one processing, with a smooth cross-section, high processing accuracy, and fast speed; It can replace traditional wire saw cutting operations, and the equipment adopts pneumatic clamping and automatic feeding, with simple and practical operation, suitable for all solid wood furniture factories.

Features
1. This machine adopts a humanized industrial control system with a user-friendly operation interface, no need for supporting software programming, and simple and efficient operation
2. The equipment realizes CNC automation processing, eliminating the template making, marking operation, wire saw cutting and rough machining process in the traditional irregular solid wood panel cutting production process, simplifying the operation process, and making one-time processing very practical

3. Automatic feeding during the machining process of this machine, especially for cutting and processing large solid wood panels with irregular shapes, is convenient and practical
4. Equipped with a high-power tool changing spindle and a long blade fixing device, suitable for high-speed cutting of thick solid wood panels and ensuring stable operation without cutting

Technical Specifications:
Product model: M3.1-1020/M3.1-1315
Travel range: 1300 × 2050mm/1300 × 1550mm
Maximum processing size: 1000 × 2000mm/1300 × 1500mm
Fast moving speed: 60m/min
Maximum processing speed: 20m/min
Transmission form: XY rack/Z screw
Table form: movable bar workbench
Material grabbing device: pneumatic clamp
Material pressing device: Material pressing drum
Spindle parameters: 9KW/24000rpm
Drive system: servo
Power and voltage: 15KW, 3P AC 380V/50HZ
Air pressure: ≥ 6.5Kgf/cm ²
Whole machine weight: 2500KG
Dimensions: 3150x2800x1700mm
