M5.2-1124 Wooden Door Comprehensive Processing Center

Pinmai CNC Comprehensive Wooden Door Processing Center (Door Lock Machine) is a fully automatic wooden door processing equipment specially designed for solid wood door square and hinge hole lock hole processing. The equipment can not only automatically adjust the two ends and sides of the wooden door to meet the required composite size, but also drill and pin the spray painting process holes on both ends and lock hole hinge hole processing. It combines traditional lock hole hinge hole machines and square four side saws into one, reducing work steps and greatly improving processing efficiency.

Numerical control door lock machine is a very important equipment in woodworking machinery. The door lock machine is mainly used to process wooden doors, door frames, door locks, door lock steps, hinge holes, and process holes in one go; Used for milling and drilling slot holes in the shape of wooden door flat and side lock holes, facilitating and accurately controlling the processing and production requirements of door lock slots and hinge holes. The door lock machine is composed of mechanical components such as vertical spindle, horizontal spindle, imported bar worktable, high-precision four milling head, auxiliary loading and unloading, and follow-up tool magazine. These components work closely together, coordinate with each other, have high processing efficiency, and are easy and convenient to operate.

Equipment characteristics:
1. Special door lock control system, door lock design suitable for various door types, one click slotting, convenient and efficient.
2. The side lock hole adopts milling cutter swing device, variable frequency motor, vacuum suction door panel, and automatic milling forming.
3. Linear guide rails are used for both horizontal and vertical directions, with high precision and long service life.
4. The cutting tool adopts a new type of milling cutter, motor, and variable speed drill set configuration, which provides better performance.

Applicable industries:
The milling and drilling of lock holes on the side of solid wood doors, as well as the milling of hinge holes on solid wood doors, can also be used for slotting and drilling holes in wooden furniture.
Technical Specificationstable

Machine tool model	M5.2-1124
Maximum processing door panel length	2400mm
Maximum processed door panel width	1100mm
Maximum processed door panel thickness	80mm
Maximum feed rate	60m/min
Maximum processing speed	20m/min
Lock hole motor 1#	9KW
Lock hole motor 2#	7.5KW
Hinge motor	2.2KW
Machine weight	3500Kg
Total power	30KW
host size	3650×2200×2300mm
