Stirring and granulating machine

Product Introduction

Trial video of stirring and granulating machine

The agitator granulator is designed and manufactured using a new wet continuous push rod granulation process. This machine can not only pelletize various organic substances, especially coarse fiber materials that are difficult to pelletize using conventional equipment, such as crop straw, wine residue, bacterial residue, medicine residue, animal manure, etc., but also achieve good granulation effects on raw materials such as humic acid and urban sludge after fermentation.

Stirring gear granulator rotor

The agitator granulator consists of a body part, a granulator rotor part, and a transmission part.

Stirring and granulating machine

The working principle of the agitator granulator is that the material enters the machine from one end of the body through the feeding port, and is continuously pushed by the granulating rotor and mechanically moved with the machine casing to achieve the purpose of granulation. The finished particles are pushed out of the machine at the other end of the body.

The rotor is driven by the motor and reducer of the transmission device, and the transmission and body parts are mostly fixed on the same frame. This not only has a sturdy structure and smooth operation, but also makes installation very convenient. It is a new era of environmentally friendly fertilizer production equipment.

Stirring and granulating machine

Characteristics of Stirring Granulator

It has the characteristics of uniform granulation, minimal particle return, high production capacity, compact and sturdy structure, easy installation and use, and stable performance.

1. The structure of the toothed granulator is novel and reasonable, with reduced weight and height. The process layout is flexible and convenient, suitable for the renovation of old factories.

2. The market tilt angle can be adjusted. Using angle washers for flexible and convenient adjustment.

3. Adopting a unique non powered combination scraper integration reduces auxiliary power consumption.

4. The market is composed of a market body and market segments. Reduce the power of the main motor. The disc joint can be adjusted up and down along the disc body. The end of the disc is a flange, which ensures that the material ball is not pulled or torn when it is released from the disc.

5. The brand new dredging design uses a non powered combination scraper to clean the edges and bottom, a corner cleaning scraper to clear the corners, and a unique processing technology for the disc body. The dredging effect is good, and there will be no large mud lumps. The diameter of the material ball is 90% between 3-5mm.

Technical parameters of agitator granulator
