VXK/VTK-A integrated intelligent monitoring terminal

VTK-A Integrated Intelligent Monitoring Terminal 4S Energy Equipment Management System

VTK-A + VXKThe integrated intelligent touch screen achieves the following functions:

VXK/VTK-A integrated intelligent monitoring terminal

online monitoring：Real time monitoring of three-phase voltage, current, power, frequency, power factor, three-phase imbalance rate, residual current access1Temperature sensor inside the cabinet3Road sensor access.

Smart Control：matching2Road switch input/output3roadRS485interface，Can be matched with intelligent touch screen，Implement remote/Local intelligent control.

VTK-B integrated intelligent monitoring terminal

matchingVXKThe integrated intelligent touch screen achieves the following functions：

online monitoring：2Road switch input/output(Scalable to8road)，4Road analog input(optional)，2Road analog output(optional)，4 Road temperature collection(optional)，4roadRS485interface；

Smart Control：Balanced wear and tear, intelligent energy-saving control；

Operation Protection：Hot overloadProtection functions such as leakage protection, uneven street protection, etc;

Startup method：directstart, SoftStartDynamic and variable frequency starting；

Integrated intelligent monitoring terminalVTK-C

Integrated intelligent monitoring terminalVTK-C-12

Can be paired with a switch panel orThe integrated intelligent touch screen achieves the following functions:

·4/8/12/16road16Aoutput unit;

·Equipped with zero crossing protection function;

·Equipped with switch logic control and multi scenario task functionality.Delay switch, preset scene threshold switch and other functions;Can be connected to external sensors such as human body sensors and illuminance sensors,Switch on/off according to light intensity, personnel situation, etc.

VXKIntelligent touch screen

VXK-7PIntelligent touch screen

VXK-2Intelligent touch screen

·Realize electrical parameter display, temperature display, local control, and intelligent inspection operation(optional)and other functions；

oneIntegrated Communication Management MachineVK-TX

Implement the following functions:dataSignal acquisition, conversion, analysis, and transmission;

VK-WGserial port server

VXK/VTK-A integrated intelligent monitoring terminal

Integrated control box for strong and weak electricity
