ZS-KX-320 vertical unboxing machine

Introduction to vertical unboxing machine: simple and fast conversion of insensitive small switches and valves

Introduction to vertical unboxing machine:

Simple and fast conversion of insensitive small switches and valves, fully mechanical design with minimal maintenance
Product model: ZS-KX-320
◆ Material: Carbon steel
◆ Purpose: Box opening and bottom sealing
◆ Specification: L2000 × W1900 × H1450mm

Process diagram of vertical unboxing machine:

Technical characteristics of vertical unboxing machine:

◆ Automatically complete the unboxing, forming, and folding of the bottom, and now complete the tape pasting of the lower part. The box board stacked into cardboard is automatically opened, and the bottom of the box is folded according to a certain program and sealed with tape before being transported to the specialized equipment of the packing machine. The automatic unboxing machine is a production line equipment that automatically opens large quantities of cardboard boxes, folds down the cover, and seals the bottom tape.

This machine adopts PLC+display screen control, which greatly facilitates operation and management, reduces production personnel and labor intensity, and is an essential equipment for automated large-scale production. Easy to operate and reduce production costs.

Folding and grabbing type: automatically corrects the right angle and accurately pushes the box open without error

◆ Compact design: easy to install

◆ Container supply device: Large and small cardboard boxes, accurate

Adhesive tape bonding at the bottom: Clean, accurately, and gently place the box into it

Technical parameters of vertical unboxing machine:

Machine model: ZS-KX-320

◆ Unboxing capacity: 10-12 boxes/minute

◆ Temporary storage capacity of cardboard boxes: 100pcs (1000mm)

◆ Carton size: L: 200-450 W: 150-400 H: 100-350mm

◆ Electricity usage: 220V 1 ф 200W

◆ Necessary air pressure: 6kg/square centimeter

Air consumption: 450NL/min

Mechanical dimensions: L2000 × W1900 × H1450mm

Mechanical weight: 450kg

Adhesive tape size: 48, 60, 72mm (choose one to use)

Mechanical weight: net weight 400kg, gross weight 550kg

Main configuration of vertical unboxing machine:
