DEG electronic level (division value 0.01~0.001mm/m) is suitable for measuring small angles and is widely used for measuring the straightness and flatness of workpiece surfaces. It has the characteristics of high measurement accuracy, good stability, small size, and easy portability. Suitable for checking the flatness of various machine tools and other equipment guide rails, the correctness of the horizontal and vertical installation positions, and the ability to check small inclination angles. It can measure the flatness of flat plates, the perpendicularity of angle and square rulers, the parallelism of flat rulers, and the straightness of straight rulers. It is widely used in the fields of measuring tool processing, mechanical assembly, and metrological calibration.
Features:
Multi functional digital display screen button operated panel
Two levels of division values are available for selection
Reading memory function: Reading can be saved and read
Zero position adjustment can be manually or automatically adjusted, with a wide range of zero adjustment
Wide range of measurement benchmark selection
Compliant with engineering standards
Rechargeable lithium-ion batteries can be recycled, with automatic voltage measurement and low voltage warning upon startup
The RS232 output interface of the digital circuit standard can be connected to a computer (without the need to purchase an additional A/D conversion interface)
Internally, the integrated circuit has high adaptability to the environment and good stability. The 360 ° rotating detachable handle can detect the verticality and flatness of large components using Sino US joint venture technology
The DEG electronic level measuring system can measure the flatness of a flat plate; The perpendicularity of angle and square rulers; The parallelism of a ruler; Measure the straightness of the ruler and print the test results. It can also be connected to other instruments to expand its application space.
Instructions for use
The DEG electronic level measurement system consists of four parts: electronic level, connecting cable, computer, and measurement software.
Connect the electronic level to the computer via RS232 interface using a cable. By using operational measurement software to collect data and select detection methods, the flatness, straightness, verticality, and other data results of the workpiece can be calculated in a timely and accurate manner. By using wireframes and anti distortion diagrams, one can intuitively understand the measurement situation and complete the work quickly and efficiently.
Features
Humanized operation interface, concise, efficient and comprehensive detection methods, tailored to different measurement objects to meet different requirements for 3D graphic browsing, making it easy for you to store and print the detection results at a glance

Company commitment: Quality service commitment:

1. Warranty period of one year, lifetime free maintenance.

During the warranty period, except for human factors, we will repair or replace any defects or malfunctions caused by improper instrument design, materials, or processes free of charge.

3. Upon receiving notification from the user that the provided instrument has malfunctioned, respond within ten minutes

4. Ensure timely provision of necessary spare parts and accessories to users at discounted prices
