Three parameter sunshine meter price model: JY-JT-IIA Jinyang Wanda

Three parameter sunshine meter price model: JY-JT-IIA Jinyang Wanda

Under natural sunlight, the three parameter sunshine meter continuously changes the altitude and azimuth angles of the sun due to the Earth's orbit around the sun and rotation. The values of these changes depend on three main parameters: measurement time, latitude and declination of the measurement location. The three parameter sunshine meter is designed based on the above principles. The JY-JT-IIA sunshine meter can be used to draw bar shadow maps and directly observe the shadow changes of buildings at a certain time and place through the model. It can also be used to observe the indoor sunshine duration, sunshine area, and shading of sunshades. It can also be used to observe the relationship between building orientation and spacing.
This sunshine meter adopts screw drive and is a stable new generation sunshine meter. There is a revolutionary improvement compared to traditional rough machining sunshine meters; At the same time, the hinge connection method is used at the center of the panel, which truly realizes the experimental panel, and there will be no obstruction of parallel light sources by the structure itself at any latitude; Due to the adoption of humanized design, the operation is extremely convenient; The height of the shadow stick can be directly read from the device and can be adjusted freely.
Purpose:
Mainly used for teaching and scientific research, conducting lighting experiments for stick shadow images or directly observing research models, and can be combined with digital imaging technology for practical research.
main parameter
Weight: 20Kg
Size: Length X Width X Height 600x400x800mm
Panel diameter: 600mm
Simulated latitude range: Full latitude (plus or minus 90 degrees)
Materials: Steel and Aluminum Alloy
Color: Black
Parallel light source parameters:
Parallelism: 6-meter range aperture diameter<1.2 meters
Light source: Cold light source
Fluctuations lt; 5lux
Power Supply and Power: 220V 50Hz 575W
Start time: 1 minute to reach steady state

Company commitment: Quality service commitment:

1. Warranty period of one year, lifetime free maintenance.

During the warranty period, except for human factors, we will repair or replace any defects or malfunctions caused by improper instrument design, materials, or processes free of charge.

3. Upon receiving notification from the user that the provided instrument has malfunctioned, respond within ten minutes

4. Ensure timely provision of necessary spare parts and accessories to users at discounted prices
