Explosion proof infrared gas analyzer (non dispersive infrared gas analyzer) model: GXH-510EX Jinyang Wanda

Explosion proof infrared gas analyzer (non dispersive infrared gas analyzer) model: GXH-510EX Jinyang Wanda

Introduction:
Used for continuous analysis of the content of a gas such as CO, CO2, SO2, CH4, NH3, etc. in a mixture of multiple gases. Applied to explosion-proof applications in industrial control fields such as petroleum and chemical engineering. Belongs to non dispersive infrared analyzer. Its working principle is based on the selective absorption of infrared radiation by certain gases. The instrument uses a single light source, a single tube half chamber, a highly stable and reliable micro acoustic thin film detector, and a new type of thermoelectric detector. Compared with similar products, the major features of this product are high stability (stable long-term operation of the instrument, small zero drift), high reliability, and high selectivity.
Technical Specifications:
1. Explosion proof level: CT6
2. Protection level: IP66
3. Range: CO: 0-20ppm; CO2：0-10ppm； O2：0-1%； CH4：0-100ppm； SO2:0-300ppm； NH3: 0-500ppm, etc.
4. Resolution: 0.01%
5. Repeatability: ≤ 1%
6. Zero drift: ≤± 2% F.S/7d
7. Range drift: ≤± 2% F.S/7d
8. Linear error: ≤± 2% F.S
9. Weight: Approximately 40Kg

Key Features:
Standard 19 chassis
Two display modes: large screen LCD display and digital display.
One instrument can provide two ranges, with a ratio of no more than 1:10 between the two ranges.
The signal output is synchronous, and the current output load is ≤ 400 Ω.
This instrument has two sets of adjustable point outputs (220VAC/0.5A), each providing one normally open node and one normally closed node. (Optional)

Ordering Notice: To ensure the accuracy and applicability of the analyzer you ordered, please fill in the following information:

1. The test group and its actual concentration range. 2. The range of the required analyzer. 3. The components and actual concentrations contained in the background gas. 4. Measure the pollution of gases, such as tar mist, flue dust, corrosive components, moisture, etc. 5. An attachment is required. 6. Other requirements.

Company commitment: Quality service commitment:

1. Warranty period of one year, lifetime free maintenance.

During the warranty period, except for human factors, we will repair or replace any defects or malfunctions caused by improper instrument design, materials, or processes free of charge.

3. Upon receiving notification from the user that the provided instrument has malfunctioned, respond within ten minutes

4. Ensure timely provision of necessary spare parts and accessories to users at discounted prices
