Four column universal material testing machine

NegotiableUpdate on 01/17

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

Four column universal material testing machine product introduction Four column universal material testing machine adopts gantry frame or single column structure, sensor force measurement system, synchronous motor speed regulation, ball screw, synchronous belt drive

Product Details

Four column universal material testing machine

Product Introduction

The four column universal material testing machine adopts a gantry frame or single column structure, a sensor force measurement system, synchronous motor speed regulation, ball screw, and synchronous belt transmission.

It can accurately measure the physical performance data of various materials under tension, and has a display window for force and displacement curves.

Suitable for testing materials such as rubber, plastic, aluminum-plastic pipes, composite materials, waterproof materials, protective materials, yarns, fibers, cables, paper, springs, wood, packaging materials, tape, etc.

By using different fixtures, it is possible to perform stretching, compression, three-point bending, four point bending, shearing, tearing, peeling, finished shoe puncture, cardboard box holding pressure, foam cyclic compression, spring tension and compression, and various dynamic and static cyclic tests.

Standards

according to GB/T 8808 、GB/T 13022、GB/T 1040、GB/T 4850、GB/T 7753、GB/T 7754、GB/T 453、GB/T 17200、GB/T 16578、GB/T 7122、GB/T 2790、GB/T 2791、GB/T 2792、ASTM E4、ASTM D828、ASTM D882、ASTM D1938、ASTM D3330、ASTM F88、ASTM F904、ISO 37、JIS P8113、QB/T 2358、QB/T 1130、GB/T16491-1996 Automatically calculate parameters such as compressive strength, yield strength, elongation, constant elongation stress, constant stress elongation, and spring modulus based on the standard.

Product parameters

Maximum force value	2 tons (vertical direction)
Load decomposition degree	1/100000
Load accuracy	±0.5%
Effective testing width	2000mm
test speed	0.1~500mm/min
speed accuracy	0.5%±
software	Position pulse control of phase-locked loop
electrical machinery	servo motor
Stroke	2600mm
Unit switching	t、kgf、 g、n、kn、lbf、mm、cm、inch
Displacement resolution	0.001mm
Force resolution	0.001kg
Transmission rod	High precision ball screw
Use power supply	220V 50HZ
