LB-3D Intelligent Disintegration Time Limit Tester

Shanghai Huanghai Drug Testing LB-3D Intelligent Disintegration Time Limit TesterProduct Introduction

The LB series disintegration time limit tester has been used in the field of drug analysis for over 40 years, strictly following the current specifications of the Chinese Pharmacopoeia. It is used for the disintegration of solid preparations such as tablets, sugar coated tablets, film coated tablets, enteric coated tablets, paste tablets, and gel coated tablets under specified conditions.

Built in three-level user permission management, audit tracking, and test record management. Test reports can be printed or USB output through device interfaces.

Common sample information management for easy retrieval and use.

High precision real-time constant temperature control, with dual over temperature protection and temperature calibration functions.

There is an internal reservation heating system, and users can set the system to start heating at a specified time.

Use more convenient water circulation pipeline design and professional medical grade quick connectors.

Free provision of IQ/OQ certification documents.

Shanghai Huanghai Drug Testing LB-3D Intelligent Disintegration Time Limit TesterTechnical Specifications

Product Code: 10107104
Collapse basket: 3 sets (6 tubes)
Hanging basket lifting frequency: 25~35 times/minute
Hanging basket lifting amplitude: 55 ± 1.0mm
Minimum distance from sieve to cup bottom: 25 ± 1.0mm
Mesh aperture: standard 2.0mm, optional 0.42mm, 0.71mm, 1.0mm
Temperature regulation range: Room temperature~45.0 ° C
Temperature resolution: 0.1 ° C
Temperature control accuracy: ≤± 0.3 ° C
Disintegration time limit: ≤ 100 times
Disintegration timing time: ≤ 999 hours, 59 minutes, and 59 seconds
Power supply: AC220V ± 10%, 50Hz
