TPY-2 Intelligent Transdermal Diffusion Tester

Shanghai Huanghai Drug Testing TPY-2 Drug Transdermal Diffusion TesterProduct description

TPY-2 drug transdermal diffusion tester is a product jointly developed by our company and the National Engineering Research Center for Pharmaceutical Preparations. Vertical wet method and horizontal dry method, in a dual-purpose constant temperature container with magnetic uniform stirring, slowly penetrate through animal skin to objectively reproduce the pharmacological process of drug penetration speed and degree in solvent. The various indicators of the instrument are stable and reliable, making it the best detection instrument for transdermal diffusion in the pharmaceutical and cosmetics industries.

Six sets of horizontal diffusion tanks can be installed.
12 sets of vertical diffusion tanks can be installed.
The working parameters of the host can be pre-set and automatically stored, so there is no need to set them again the next time it is turned on.
The timing function displays the current sampling point time and the total number of sampling points accumulated over time.
It has a fault self diagnosis function.
Can be connected to an external micro printer function.
Equipped with USB storage function to retain experimental data for easy viewing.

Shanghai Huanghai Drug Testing TPY-2 Drug Transdermal Diffusion TesterTechnical Specifications

Product Code: 10107102
Number of vertical diffusion tanks: 12 sets
Vertical diffusion pool volume: 8ml
Number of horizontal diffusion tanks: 6 sets
Horizontal diffusion pool volume: 7.5ml × 2
Speed setting range: 100~500RPM
Steady speed error: ≤± 1%
Temperature regulation range: Room temperature~45.0 ° C
Temperature resolution: 0.1 ° C
Temperature control accuracy: ≤± 0.3 ° C
Sampling frequency: ≤ 10 times
Sampling timing time: ≤ 99 hours, 59 minutes, and 59 seconds
Power supply: AC220V ± 10%, 50Hz
