LS-3000 Low Temperature Drug Illumination Tester - Shanghai Huanghai

Yellow Sea Drug Testing LS-3000 Product Usage:

Drug and raw material light test

Raw material testing in the field of cosmetics

Lighting tests in other fields

Yellow Sea Drug Testing LS-3000 Product Features:

1Illumination closed-loop control

Realize automatic illumination control through a microprocessor to ensure uniform illumination.

2. Fuzzy temperature control technology

By real-time monitoring of the studio temperature through microprocessing, based on the relationship between the working time of the compressor and the temperature change in the studio, the cooling demand of the environment (including the sample to be tested) can be inferred, and the start and stop time of the compressor can be accurately controlled. Compared with traditional mechanical temperature control devices, this significantly improves the temperature stability of the studio.

3. Larger illumination range and more stable illumination

Compared with other light sources, LED light sources have excellent stability and do not require start-up stabilization time. After long-term use, the brightness change is also very small. In addition, the instrument uses LED constant current brightness control technology to make the illumination adjustment range wider.

4. Experiment completion reminder

When the experiment time is up, the instrument will emit a prompt sound, and users can also set the light source to automatically turn off, cooling to automatically turn off, or all to turn off after the experiment is completed.

5. User friendly interface

Introducing modern technological achievements into instrument design to provide users with a good operating experience, the display screen can display information such as temperature, illumination, and remaining experimental time. Due to the absence of mechanical knobs and switches, the reliability and stability of the system have been improved.

6. New type of LED semiconductor light source

Among existing light sources (incandescent lamps, energy-saving lamps, LED lamps), LED light sources have the highest efficiency, ten times that of incandescent lamps, twice that of energy-saving lamps, and a lifespan twenty times that of energy-saving lamps. High efficiency means lower heat generation. The instrument uses high-efficiency LED semiconductor light sources, further reducing the thermal radiation generated by the light source on the sample.

7. UV light source (UV type)

On the basis of LS-3000/4000/5000, a UV light source with a center wavelength of 365nm has been added, which meets the requirements of the ICH Stability Testing Guidelines for UV light sources, has a long lifespan, and stable energy.

Yellow Sea drug testing LS-3000 technical parameters:

Temperature control range: 5 ℃~room temperature

Illumination control range: 2000~5500LX

Illumination uniformity: better than ± 8% (excluding corner areas)

Studio size: 365 * 340 * 160mm

Camera resolution: -

Maximum power: 120W

Working voltage: 180~240VC 50~60HZ

Length x width x height: 430x480x510mm

Net weight: 18kg

Note: The LS-5000 has a built-in camera and comes with image software. If you need to add UV, please call customer service for consultation.
