Langxi Instrument (Shanghai) Co., Ltd
Online gas chromatograph
NegotiableUpdate on 03/04
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
Brief description: LX-3000 online gas chromatograph is an A-level high-tech achievement transformation project in Shanghai. The product has a program heating function, and the instrument adopts advanced Ethernet communication interface to directly connect to the computer and the Internet. It is equipped with a single independent connection process and built-in Modbus/TCP server, which can easily connect the analysis results to DCS (distributed control system) for real-time transmission of online analysis data. Equipped with a built-in industrial grade computer and an embedded touch LCD display, the display is intuitive and the operation is convenient. The full air flow display function can better make the operator more intuitive and convenient.
Product Details
Details
| brand | Self operated brand | Instrument type | on line |
|---|---|---|---|
| Origin category | domestic | Price range | discuss personally |
| Applications | general use | application area | Environmental protection, chemical industry, petroleum, energy, electronics |
LX-3000Online gas chromatographIt is an A-level high-tech achievement transformation project in Shanghai. The product has a program heating function, and the instrument adopts advanced Ethernet communication interface to directly connect the computer and the Internet. It is equipped with a single independent connection process and a built-in Modbus/TCP server, which can easily input the analysis results into DCS (distributed control system) for real-time transmission of online analysis data. Equipped with a built-in industrial grade computer and an embedded touch LCD display, the display is intuitive and the operation is convenient. The full air flow display function can better make the operator more intuitive and convenient.
2、 Technical parameters:
| LX-3000 seriesOnline gas chromatograph | |
| control mode | Built in 10 inch touch industrial computer |
| detector | PDDID, TCD, FID, FPD, PED, ADD, ZrD, PID, etc |
| Temperature controlled area | Route 8 |
| TPD | 20th order |
| column oven | Room temperature: 4 ℃~450 ℃, increment: 1 ℃, accuracy: ± 0.1 ℃ |
| Cheng Sheng rate | 0.1～60℃/min |
| press programming | 8th order (optional) |
| LRV | nL/L、μL/L、% |
| Drift/repeatability | ±1%～±5% |
| Sample gas flow rate | 30～100mL/min |
| Sample gas pressure | 0.1MPa |
| Carrier gas type | He（or N2、Ar、H2） |
| carrier gas flow | 30～150mL/min |
| Carrier gas pressure | 0.4 MPa |
| power supply | 220V±22V，50Hz |
| energy consumption | 1200W (small power optional) |
| weight | 15kg |
| size | Standard 6U chassis (non-standard optional) |
| 482mm（W）×267mm（H）×500mm（D） | |
| flow control | EPC、 Flow meter and electronic monitoring are optional |
| Workstation online display | The technology used directly displays the analysis results, reads them directly, and can print the results directly; Debugging parameter data requires authorization codes to ensure accurate and reliable analysis of data, making laboratory management more effective and data more secure. |
| output | 4～20mA、RS232/RS485、 Ethernet |
3、 Application Fields
Industrial gas field:
- Air Separation Unit (ASU)
- CO2、H2、He
- electron gas
- corrosive gas
?
In the field of electricity/gas:
- transformer
- sf6
- gas
- Coal gasification/liquefaction
?
Steel industry:
- blast furnace
- converter
- coke oven
- shielding gas
?
In the field of petrochemicals:
- ethylene plant
- Acrylonitrile plant
- Polymer factory
- Petrochemical refining plant
?
Natural gas field:
- Light hydrocarbon
- reactor
- heat exchanger
- Liquefied Natural Gas (LNG) Plant
?
In the field of chemical engineering:
- halogenated hydrocarbon
- Fine Chemicals
- Polycrystalline silicon manufacturing
- Cl2、 HCl、NH3
