MG-HWSG-2C fixed installation type. Aluminum alloy structure, equipped with installation brackets, divided into primary and secondary instruments. There are three types of signal outputs: 4-20mA, RS232, and BCD code; 1、 Both secondary instruments have display functions and have the ability to record large amounts of data, which can be connected to computer systems through software. A single instrument can be separately connected to the PLC measurement and control system, or connected to a multi-channel interface box. Through the exact TEMH software, it can be easily networked with a computer to form a powerful temperature monitoring system.

Technical Specifications
Measurement range: 300-800 ℃, 600-1400 ℃, 1000-1800 ℃
Temperature measurement accuracy: basic error of 1%, repeatability error of 0.3%
Working band: 2.4u, 2.1u, 2.1u, 1.6u
Measurement distance>0.5M
Distance coefficient: 150 200
Response time: 0.03 seconds/time
Display mode: 6-digit digital display on the instrument panel
Secondary instrument dual 6-digit digital display temperature and clock
Temperature measurement method: Continuous measurement at a rate of 30 times per second
Trigger method: Temperature measurement upon arrival of high-temperature objects
Both methods can choose the maximum value to be effective
Instantaneous values in data processing
average
Anti interference filtering value
Data output: RS232 serial communication with baud rate of 1200
Standard analog signal: 4-20mA
BCD code signal for external large screen temperature display
Power supply method: AC220V power supply is used in conjunction with secondary and primary instruments
Single use DC 24V primary instrument
Working temperature: 0-40 ℃, above 40 ℃ with water cooling jacket
Power consumption: ≤ 10W
Whole machine weight: 1.2kg for primary instrument and 2.0kg for secondary instrument

MG-HWSG-2D adopts a new generation of microcontrollers and integrated circuits to measure the temperature of an object by collecting, analyzing, and processing the energy of two narrow infrared bands in the object's thermal radiation. Therefore, it is less affected by the surface emissivity of the object; Strong resistance to smoke, water vapor, and environmental electromagnetic interference. Due to its fast measurement speed (0.03-0.05 seconds/time) and multiple standard signal output methods, it can directly interface with computers and printers for long-distance transmission. The software functions of the instrument are very rich. For different sites, accurate target temperature values can be obtained by setting 16 sets of optional working parameters. It is very convenient to use under various conditions and can meet the requirements of various temperature measurement sites. Small in size, light in weight, and easy to carry, the main performance indicators are at the international level, and can be widely used in temperature measurement and process research in steel rolling, smelting, heat treatment, casting, forging, kilns, chemical engineering, and steel rolling processes. Compared with traditional temperature measurement methods, it has significant advantages and superiority.

Technical Specifications:

1. Temperature measurement range: 300-2500 ℃ (graded)

2. Temperature measurement accuracy: 0.5 (basic error<1%, repeatability error<0.3%)

3. Distance coefficient: 250:1

4. Temperature measurement speed: 0.04 seconds/time

5. Temperature measurement methods: continuous and triggered

6. Output mode: Standard analog signal 4-20mA RS232 serial communication mode, baud rate 1200 BCD code signal for external large screen temperature display, temperature over limit alarm output

Company commitment: Quality service commitment:

1. Warranty period of one year, lifetime free maintenance.

During the warranty period, except for human factors, we will repair or replace any defects or malfunctions caused by improper instrument design, materials, or processes free of charge.

3. Upon receiving notification from the user that the provided instrument has malfunctioned, respond within ten minutes

4. Ensure timely provision of necessary spare parts and accessories to users at discounted prices
