1、 Product Overview

The main measuring components of the LZB series glass rotor flowmeter are a vertically installed lower small and upper large conical glass tube and a float that can move up and down inside. When the fluid passes through the conical glass tube from bottom to top, a pressure difference is generated between the upper and lower parts of the float, and the float rises under this pressure difference. When the upward force, buoyancy, and viscous lift acting on the float are equal to its gravity, the float is in an equilibrium position. Therefore, there is a certain proportional relationship between the fluid flow rate flowing through the glass rotor flowmeter and the rising height of the float, that is, the flow area of the glass rotor flowmeter. The position height of the float can be used as a measure of flow rate.

2、 Structural principle

The flowmeter is mainly composed of a conical glass tube that expands from bottom to top and a float that moves up and down with the flow rate of the fluid. When the fluid flows through the conical tube from bottom to top, the lift S generated by the kinetic energy of the fluid on the float and the buoyancy A of the fluid cause the float to rise. When the sum of the lift S and buoyancy A is equal to the weight G of the float itself, the float is in equilibrium and stable at a certain height position. The scale on the conical tube indicates the flow rate value of the fluid.
