SHC deformation small GB1002 plug gauge

German DINVDE0620-1 Lehre 3 detailed introduction

Socket socket, two pole hole spacing gauge, two pole plug insertability gauge

Product Name: VDE0620 German plug gauge, socket gauge
Technical standard: DIN VDE 0620-1

Gauge name: Gauge 3, socket socket, two pole hole spacing gauge, two pole plug insertability gauge (see 9.1)

Gauge specification: Lehre 3

Gauge type: socket gauge

Gauge model: SC-V0L3

There are many models available, please contact us for a list and detailed information.

-----------------------------------------

VDE0620 plug and socket factory audit requires the use of gauges (tools)：

The VDE 0620 gauge is as follows:

(Note that "optional" is a gauge recommended by Guangzhou Shice)

One L2B gauge (measuring the small pull-out force of the French head ground wire hole) (Sections 9.1 and 22.2)

Two L6A (a)/L6A (b) gauges (for measuring the diameter of European PIN heads) (Section 22.1)

L6B (a)/L6B (b) gauge (measuring the diameter of the French PIN head) 2 pieces (Section 22.1)

L7A gauge (measuring the outer dimensions of the first two pins in France) 1 piece (Section 9.1)

L7B gauge (measuring the center distance between the first two PINs in France) 1 (Section 9.1)

L8 gauge (measuring the diameter of the French grounding hole) 1 (Section 9.1)

L9 gauge (measuring the external dimensions of the French probe) 1 piece (Section 9.1)

L12 gauge (single pole non insertable plug) 1 piece (0.3 section) optional

1 or 2 1000g weights (to be used with L12/F4 specifications) optional

The gauges for EN 50075 are as follows:

F2 gauge (measuring the center distance of European PIN) 1 piece

F4 gauge (European head single pole non insertable) 1 optional

3. Pull out force gauge (Section 22.1.2 and Table 16)

16e gauge (18N pull-out force gauge for measuring French head ground wire hole) 1 piece

16e gauge (2N pull-out force gauge for measuring French head ground wire hole) 1 optional

---------------------------------------------------------------

Product Name: DIN VDE 0620-1 Plug Gauge and Socket Gauge from Germany
Technical standard: DIN VDE 0620-1

VDE0620 Gauge List：

1. All products undergo metrological testing and calibration by testing laboratories with CNAS accreditation (accredited laboratory qualification), and are issued with metrological certificates.
2. The gauges are strictly produced one by one according to the requirements, crafted with ingenuity.

Application and Purpose
Use gauges to check whether the corresponding plug and socket dimensions are qualified.

Contact: Mr. Zhong

Telephone:

Mobile phone: (WeChat)
QQ ：8933882

邮箱： sales@shice17.com

Website: www.shice17.cn

详细： http://www.shice17.cn/product/VDE0620-list/VDE0620-Lehre19a.html
