Ukraine OKONDT UD3-71 Ultrasonic Portable Flaw Detector

be careful! The product price is subject to the actual call back quotation! This product isDistributed by Pang Yuliang Instrument (Shanghai) Co., Ltd,If you need to purchase, you can log inWWW.HELLOINSTRUMENTS.COMTelephone consultation.

Ukraine OKONDT UD3-71 Ultrasonic Portable Flaw Detector

Ukraine OKOndt

Pang Yuliang Instrument (Shanghai) Co., Ltd. is the authorized agent of Ukraine OKOndt UD3-71 ultrasonic portable flaw detector

Ukraine OKOndt UD3-71 Ultrasonic Portable Flaw Detector Product Introduction:
Product brand: Ukraine OKOndt
Product model: UD3-71
Product category: Flaw detector
Product note: Flaw detector

Ukraine OKOndt UD3-71 Ultrasonic Portable Flaw Detector Product Description:
UD3-71 flaw detector is a universal ultrasonic flaw detector suitable for:
Non destructive testing of manual products to detect defects, such as material discontinuities and unevenness in raw materials, finished products, in-process products, welding, brazing, bolts, riveting, and other joints;
Measure the depth and depth coordinates of defects;
Measure the thickness of various items when entering in one direction;
Measure the amplitude ratio of the signal (reflected by defects);
Measurement of equivalent defect size;
Evaluate the sound velocity in debris.
The flaw detector is capable of testing materials and products at sound speeds ranging from 1500 m/s to 12000 m/s.
The UD3-71 ultrasonic flaw detector can perform testing on welded joints and base materials, and measure the thickness of single and double metals according to regulatory requirements in various industries.

Advantages of Ukraine OKOndt UD3-71 Ultrasonic Portable Flaw Detector:
*Small instrument size - not exceeding 200x100x110 mm - ensures high instrument ergonomics and ease of operation.

• Various A-scan display formats: RF/full wave/+half wave/half wave;
The dynamic changes in the generated path characteristics depend on the frequency filter that is turned on;
• Information display format: A-scan, B-scan, orthogonal diagram, corrosion diagram;
USB slave station;
The flaw detector can operate at ambient temperatures ranging from -10 ° C to+45 ° C;
The penetration protection level of the flaw detector casing for solids and water is equivalent to I Ü 65;
• Easy to disassemble batteries;

The flaw detector also has the ability to resist ionizing radiation and can operate in environments with high humidity;
Each door has two independent measuring doors with defect alarm systems (sound and light). Meanwhile, each gate has:
• Three starting levels: 'Accept'; Registration; SEARCH "is marked on the flaw detector screen in the colors of" RED "," BLUE ", and" GREEN ". The color of the alarm light for each door corresponds to it. The application of three-level gates makes it possible to estimate the risk of discovering defects.

The shutdown level of the sound alarm is set by the operator through a specific door; F
The operator sets the mode for each gate separately (whether it exceeds the preset level).

When using a three-level gate, echo signals can be registered at different levels relative to the receiving level. It will allow recording of echo signals from developing defects and monitoring of defects in the test result program to view the conditions required for ultrasonic testing (UST) of important objects. The three-level gate and convenient sound and light defect alarm system can quickly and qualitatively evaluate the detected discontinuous sizes.

Ukraine OKOndt UD3-71 Ultrasonic Portable Flaw Detector Relevant Parameters:

Ukraine OKOndt UD3-71 Ultrasonic Portable Flaw Detector Related Configuration:

*-It can be changed (or supplemented) according to the user's order in the accompanying probe terminology.
-At the factory, the conversion cable P112 can be constructively included in the probe.
-Provide according to consumer requirements.
-The type of charger may change.
