Paper faced gypsum board fire stability tester

produceproductJanebetween

Our company's paper faced gypsum board fire stability tester meets the testing requirements of national standards GB/T9775-2008 and ISO6308 "Paper Faced Gypsum Board" for fire stability. Suitable for testing the thermal stability of paper faced gypsum board when exposed to fire. This device has the characteristics of reasonable structural design, high degree of automation, accurate time recording, stable performance, and easy operation. It is an essential testing equipment for manufacturers, research institutions, and product quality supervision and inspection units.

lMain technical features:

1. The testing instrument consists of an experimental part and a control part, and adopts an integrated design;

2. The test shell and important components are made of stainless steel, which is resistant to smoke and gas corrosion. The control system has a high degree of automation;

3. Equipped with automatic ignition function, temperature and time digital display, easy to observe and record, stable and reliable;

4. Power supply: AC220V ± 10%/50Hz (other power specifications can be specified);

5. Power: 180W;

6. Gas source: liquefied petroleum gas;

7. The flame length can be easily adjusted from 20mm to 100mm;

8. The flame application time and holding time can be adjusted within the range of 0~99 minutes and 99 seconds, and the test process is automatically controlled;

9. Timing resolution: 1S;

10. Test temperature: 800 ± 30 ℃;

11. The box has a content of 0.05m3 and dimensions of 610 (width) x 350 (depth) x 650 (height);
