lOverview

The SDD-I safety glass pouch impact testing machine is a new product developed in accordance with national standards GB/T 9963-1998, GB 17 841-1999, GB9962-1999 and other technical requirements, combined with the actual situation of China's construction and production industry. This series of products fully meets the requirements of national standards and is a necessary equipment for quality inspection agencies, technical supervision departments, engineering quality supervision departments in the construction industry, scientific research units, and tempered glass production units in various regions.

For the greatest possible convenience to users, this system is equipped with corresponding hardware detection equipment. The main body adopts a base of 12 # channel steel and a specimen frame welded with 100100 square tubes, equipped with electromagnets, three-phase asynchronous motors and reducers, movable pulley groups, position switches, etc; The gearbox drives the lifting of the magazine; The mechanical arm is controlled by an electromagnet to grasp and place the ammunition bag; At the same time, electrical equipment such as position switches were used to improve the height accuracy of the grenade bag.

lAccording to the standard:

GB 15763.2-2005 Safety Glass for Building Use Part 2: Tempered Glass

GB 15763.4-2005 Safety Glass for Building Use Part 4: Homogenized Tempered Glass

GB 17841-2008 Semi tempered Glass

lMain technical parameters

1. Impact height: 300mm, 450mm, 600mm, 750mm, 900mm, 1200mm.

2. Impact height deviation: ≤± 30mm.

3. Mass of shotgun bag: 45 ± 0.1Kg.

4. Maximum radius of shotgun bag: 250mm.

5. Swing radius of shotgun bag: 1550mm.

6. Power supply requirements: AC380V, 400W.

7.Dimensions 1950x1200x3050 (length x width x height).

8. The weight of the specimen frame, operating platform, and specimen combination is approximately 350Kg.

lMain Features

Simple structure, small footprint, and easy operation;

Adopting advanced microcontroller control system, fully braking control of the lifting height of the magazine with high control accuracy.

The robotic arm is mainly composed of a robotic arm (equipped with a high-speed reaction electromagnet), a main arm, limit switches, hooks, and 7 high-sensitivity proximity sensors, which can fully achieve various impact heights required by the standard and achieve precise positioning. Limit switches can protect the robotic arm from damage in the event of overall equipment malfunction.

The power system consists of a three-phase asynchronous motor, a reducer, a fixed pulley, and a steel wire rope. The electric motor enables the magazine (driven by the robotic arm) to quickly and stably move to the impact height specified by the operator. After a long period of experimentation, modification, and running in, the entire power system can achieve almost perfect control effect. The existence of the electric motor is to quickly reach the target position, while the existence of the reducer is to achieve the target position more stably. Both are indispensable.

The control system mainly consists of key switches, buttons, and indicator lights. It is equipped with a microcontroller control system inside, which is safe, convenient, and has a clear and beautiful panel. The operation is simple and easy to learn.
