ZCA-1000AF fully automatic flame atomic absorption spectrophotometer

NegotiableUpdate on 07/29

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

1、 Performance index 1. Optical system wavelength range 185nm-910nm grating line density 1800 lines/mm monochromator aberration correction Czerny Turner type monochromator spectral bandwidth 0.1, 0.2, 0.4, 1.0, 2.0nm

Product Details

ZCA-1000AF全自动火焰原子吸收分光光度计

1、 Performance indicators

1Optical system

wavelength range	185nm-910nm
Grating line density	1800scribe/mm
monochromator	anaberrationCzerny-TurnerType monochromator
spectral bandwidth	0.1、0.2、0.4、1.0、2.0nmMulti level automatic switching
Wavelength accuracy	±0.10nm
Wavelength Repeatability	0.05nm
baseline drift	static state0.002A/30minDynamic0.006A/30min
detector	Wide spectral range photomultiplier tube
resolution	Can distinguish manganese lamps279.5nmand279.8nmDouble lines, and the energy of the valley between the two spectral lines should be less than20％

2Light source system

lamp base	8Automatic switching of lamp holder
Lamp power supply mode	400Hzsquare-wave pulse
Lamp current adjustment range	0 — 10mAaverage current

3Atomization system

Flame analysis method
detection limit(Cu)	0.003μg/ml
burner	100mmAll titanium metal burner
precision	RSD≤0.5%
sprayer	Metal sheathed high-efficiency glass spray
Atomization chamber	Corrosion resistant all plastic atomization chamber
Security measures	It has multiple automatic safety protection functions, such as acetylene leakage alarm and automatic shutdown system.

4Flame analysis method

measuring method	Standard curve method, standard addition method, interpolation method
Concentration calculation method	Automatically fitting the working curve, automatically correcting sensitivity, and automatically calculating concentration and content.
Repeated measurement times	1~99Next, automatically calculate the mean, content, standard deviation, and relative standard deviation.
Result printing	Print test data or final analysis report. The results can be exported aswordWorksheet.
software environment	Windows XP/ Windows7Operating system, professional Chinese software

2、 Instrument parameters

power supply	AC 220V/50HZ
power	150VA
Net weight of the instrument	55kg
Gross weight of the instrument	80kg
Instrument volume	1110mm(Horizontal)× 400mm(Depth)× 500mm(High)
Packaging volume	1350mm(Horizontal)× 600mm(Depth)× 850mm(High)
Ambient Temperature	10~35℃
Working environment humidity	≤80%

3、 Standard configuration

1. Host

2. Low noise oil-free air compressor

3. Hollow cathode lamp

4. Operating software

4、 Design Features of ZCA-1000AF Fully Automatic Flame Atomic Absorption Spectrophotometer

1. Total reflection optical system, full band chromatic aberration reduction, automatic wavelength scanning, and automatic peak searching.

2. The uniquely designed all titanium burner ensures smooth combustion and fast thermal equilibrium speed.

3. Automatic adjustment of negative high voltage, lamp current, optimal element lamp position, automatic ignition, and automatic shutdown protection.

The automatic control system of the 8-lamp rack (optional with 2 high-performance lamps) can adjust the hollow cathode lamp to the best position in all directions, and can set a specific element lamp position separately. The work lamp and preheating lamp can be freely set to save the preparation time of the element lamp to the greatest extent.

4. It can be upgraded to a graphite furnace atomic absorption spectrophotometer.
